概述

框图

blockDiagram

框图

Block Diagram
类别 产品 特性
功率模块驱动器
3-Phase Brushless Motor Pre-Driver 三相MOSFET预驱动器,6V-58V,-20至+105
3 Phase Field Effect Transistor Pre-driver 对于40 VDC以上的电压,采用三相FET预驱动器
控制器(MCU和DSC)
Kinetis® KV1x-75 MHz,  Entry-level 3ph FOC / Sensorless Motor Control MCUs based on Arm® Cortex®-M0+ 75Mhz CM0+ CPU with hardware square root and divide to further improve performance. Flextimer and dual ADC for low dynamic motor control applications.
Kinetis® KV3x-100–120 MHz,  Advanced 3ph FOC / Sensorless Motor Control MCUs based on Arm® Cortex®-M4 100/120MHz CM4F CPU for high performance, high dynamic applications. Flextimer and dual ADC for advanced control applications.
Kinetis KV4x-168 MHz, High Performance Motor / Power Conversion MCUs based on Arm® Cortex®-M4 168MHz CM4F for advanced single motor and multi-motor systems. 4.1MSPS ADC and advanced eFlexPWM for the most demanding applications.
Kinetis® KV5x-240 MHz, Motor Control and Power Conversion, Ethernet, MCUs based on Arm® Cortex®-M7 240MHz CM7 core, with 4x5MSPS ADC and 44 timer channels including 24ch eFlexPWM for the most demanding motor applications, combined with ENET for communications.
Digital Signal Controllers Fast ADC, 32-bit DSP core, quadrature decoder, flexible advanced timer
S12ZVM Mixed-Signal MCU for Automotive & Industrial Motor Control Applications S12Z based MCU with embedded 12V to 5V voltage regulator, LIN phy and 3phase bridge gate driver
MC56F823xx and MC56F827xx Digital Signal Controllers Low-power operation enables higher system efficiency due to lower power losses
32-bit Automotive General Purpose Microcontrollers S32K is a series of 32-bit automotive MCUs based on ARM® Cortex-M® processors with Safety and Security HW support
Ultra-Reliable MPC574xP MCU for Automotive & Industrial Safety Applications
Ultra-Reliable MPC560xP MCU for Automotive & Industrial Safety Applications
Ultra-Reliable Dual-Core 32-bit MCU for Automotive and Industrial Applications
软件和工具
FreeMASTER Run-Time Debugging Tool Real-time control and debugging tool for Digital Signal Controllers
Real Time Control Embedded Software Motor Control and Power Conversion Libraries Embedded Software and Motor Control Libraries
Model-Based Design Toolbox A comprehensive collection of tools that plug into the MATLAB®/Simulink® model-based design environment to support rapid application development with NXP® MCUs
Motor Control Application Tuning (MCAT) Tool
通信
Power Supply with Multiple Linear Regulators 带多个线性稳压器的开关电源
High-Speed CAN Transceiver Auto Applications 高速CAN I/F
SBC Gen2 with High-Speed CAN and LIN 带有LIN和高速CAN接口的系统基础芯片
System Basis Chip Gen2 with High Speed CAN 带高速CAN接口的系统基础芯片
SBC Gen2 with High-Speed CAN and LIN 带有LIN和高速CAN接口的系统基础芯片
5.0A 1.0MHz Integrated Dual Switch-Mode Power Supply 5.0A,0.7V/3.6V可调,双路开关电源
FET
NextPowerS3 low voltage, high current, fast switching power MOSFETs
Robust MOSFETs for battery-powered motor-control applications
