NXP has helped to shape the hearing aid market for the past two decades, supplying silicon for more than a third of
the hearing
aids currently on sale. The NXH2004
is changing the game in terms of audio quality, features and processing.
A New World of Possibilities
The NXH2004 is one of the NXP wireless connectivity solutions for hearing health. Building on the success of previous
generation
solutions, it features Bluetooth® LE Audio and
Auracast™ broadcast audio, and enables advanced
audio sharing
as well as enhanced clarity, all contributing to a better quality of life for the hearing impaired.
Individuals wearing hearing health devices enabled by the NXH2004 will be able to enjoy enhanced audio from up to
five different
sources for the very first time, thanks to Bluetooth LE Audio. This opens up an exciting new world of possibilities,
not only
for those with hearing difficulties themselves, but also for their families, housemates or caregivers.
Seamless connectivity for hearing impared
Wearers can stream audio directly from their laptops while also having a conversation on their mobile phone, for
example, with
both devices actively connected by the NXH2004. Such functionality enables individuals to stream music or audio from
their
mobile phones and TVs simultaneously, being able to enjoy additional clarity without increased volumes impacting
other family
members. Multiple channel support even extends to streaming audio between the earbuds themselves, enabling excellent
hearing enhancements.
Along with being NXP’s first hearing health solution to incorporate Bluetooth LE Audio, the NXH2004 is also NXP’s
first device
to offer Auracast broadcast audio, providing life-changing opportunities when it comes to wider accessibility.
The broadcast technology adopted in classrooms, conference rooms and other locations, is providing hearing support
in situations
where it can be particularly difficult to hear. The NXH2004’s Bluetooth LE Audio functionality means that searching
for Auracast
broadcasts and connecting to them is as simple as joining a WiFi network.
Hearing loss presents substantial obstacles in an individual's life. Explore NXP’s
comprehensive offering for next generation
electronic hearing aid
designs.
Seamless Connectivity
The NXH2004’s connectivity extends further, supporting MFI (Made for iPhone) and
ASHA (Audio Streaming for Hearing Aids), along with Bluetooth’s
Hearing Access Profile
1.0.
MFI enables NXH2004 wearers to stream audio to hearing aids from their iPhone, iPad and other Apple devices. ASHA
provides
similar hearing aid streaming solutions for those using Android devices.
Hearing Access Profile, meanwhile, defines the requirements for Bluetooth devices necessary for interoperability
within the
hearing aid ecosystem. It also specifies behaviors related to audio streaming and remote control of the hearing aid
using the
Bluetooth framework; and the NXH2004 is fully compliant.
Future applications for NXP’s latest audio SoC are equally transformative, with the potential to use the chip
alongside
applications like hearing glasses, with interfaces to support health and wellness tracking applications.
NXH2004 block diagram
A Fully-Featured Solution In An Incredibly Small Package
The NXH2004 features a miniaturized form factor, measuring in at just 9.1 mm². Despite the size, it’s packed with
technology.
The SoC includes two Arm® Cortex® M0+ cores and dual Audio DSP processors to handle multiple channel support quickly and
efficiently,
with no audio distortion.
With 640 kB Flash, 160 kB RAM, and 128 kB ROM onboard, the NXH2004 delivers incredibly low latency. At 20 ms, the
NXH2004 delivers virtually lag-free audio processing. The 2.4 GHz radio transceiver also features low power
consumption, contributing to a solution that requires only 1.2 V to operate, with additional run time possible via
Zn-Air
battery support.
It’s as an all-round package that the NXH2004 really excels. The combination of an ultra-small design,
matched with
high-quality audio and the potential for multiple audio streams, makes NXP’s recent wireless connectivity solution
for hearing
health a solution that can genuinely transform lives.
