S12ZVMA: Mixed-Signal MCU for Automotive & Industrial Motor Control Applications

Overview

Features

DC Motor Application Using S12ZVMA MCU

DC Motor Application Using S12ZVMA MCU

Simplify your system design and reduce time to market with integrated S12 MagniV® solutions

Simplify your system design and reduce time to market with integrated S12 MagniV<sup>&#174;</sup> solutions  thumbnail

S12 MagniV Microcontrollers for Automotive Applications

S12 MagniV Microcontrollers for Automotive Applications thumbnail

Get your DC-motor to spin using S12ZVMA MagniV® MCUs and CodeWarrior®

Get your DC-motor to spin using S12ZVMA MagniV<sup>&#174;</sup> MCUs and CodeWarrior<sup>&#174;</sup> thumbnail

Target Applications

S12ZVMA Comparison Table

S12ZVMA Family
Product Name VMAL32 VMAL16 VMAL32 VMAL16 VMA32 VMA16 VMA32 VMA16
Communication Physical Layer (PHY) LIN High Voltage PWM
Packages 48 LQFP 32 LQFP 48 LQFP 32 LQFP
Flash (bytes) 32 KB 16 KB 32 KB 16 KB 32 KB 16 KB 32 KB 16 KB
EEPROM (bytes) 128
RAM (bytes) 2 KB 1 KB 2 KB 1 KB 2 KB 1 KB 2 KB 1 KB
Vreg 12V supply; 5V/70mA
N-ch FET predriver / GDU (HS / LS) 1/1 1/0 1/1 1/0
External FET 50-80nC total gate charge
Charge Pump Yes
Integrated Bootstrap Diode Yes
Integrated Current Sense Op-Amp Yes
10 Bit ADC (ext. channels) 7 4 7 4
SCI 1 (routed to LIN-PHY)
SPI 1
Internal timers TIM + RTI + API
TIM (IC/OC channels) 2ch + 2ch 16-bit
PWM 6ch PMF (2 x GDU, 4 x GPIO)
EVDD (25mA sink) 1
Temperature Options V / M / W (up to 150°C Ta) V / M (up to 125°C Ta) V / M / W (up to 150°C Ta) V / M (up to 125°C Ta)

What's New

S12ZVMA-WN-IMG
Training

Easily Develop LIN-based Actuator Applications

Using Mixed-signal MCUs, using the S12ZVMAEVB evaluation board on the NXP CodeWarrior® for MCUs v11.0
