The i.MX RT series of crossover MCUs are part of the EdgeVerse™ edge computing platform and feature the Arm® Cortex®-M core, real-time functionality and MCU usability at a cost-effective price.

Product selector Cross Reference

Choosing the right product just got easier. View all product finding tools.

i.MX RT Products

Key Features
Product CPU Package Memory
Graphics
Acceleration
Display
Interfaces
Camera
Interfaces
Audio USB with PHY Ethernet CAN
i.MX RT1180 [1] Cortex-M7 @800 MHz +
Cortex-M33 @240 MHz 		289 BGA
144 BGA		 1.5 MB SRAM - - - 4 x I2S, S/PDIF, DMIC 2 1 x independent 1 Gbit/s
TSN MAC end point 5-port (4 external + 1 internal)
TSN Switch with 1 Gbit/s TSN MAC, EtherCAT, OPC UA 		3 x CANFD
i.MX RT1170 Cortex-M7 @1 GHz +
Cortex-M4 @400 MHz 		289 BGA 2 MB SRAM 2D GPU, P x P Parallel, MIPI Parallel, MIPI 4 x I2S, S/PDIF, DMIC 2 2 x Gbit/s, 1 x 10/100 3 x CANFD
i.MX RT1160 Cortex-M7 @600 MHz +
Cortex-M4 @240 MHz 		289 BGA 1 MB SRAM 2D GPU, P x P Parallel, MIPI Parallel, MIPI 4 x I2S, S/PDIF, DMIC 2 1 x Gbit/s, 1 x 10/100 3 x CANFD
i.MX RT1064 Cortex-M7 @600 MHz 196 BGA 1 MB SRAM,
4 MB Flash 		P x P Parallel Parallel 3 x I2S, S/PDIF 2 2 x 10/100 2 x FlexCAN, 1 x CANFD
i.MX RT1060 Cortex-M7 @600 MHz 196 BGA
225 BGA		 1 MB SRAM P x P Parallel Parallel 3 x I2S, S/PDIF 2 2 x 10/100 2 x FlexCAN, 1 x CANFD
i.MX RT1050 Cortex-M7 @600 MHz 196 BGA 512 kB SRAM P x P Parallel Parallel 3 x I2S, S/PDIF 2 1 x 10/100 2 x FlexCAN
i.MX RT1040 Cortex-M7 @600 MHz 169 BGA 512 kB SRAM P x P Parallel - 3 x I2S, S/PDIF 1 1 x 10/100 2 x FlexCAN
1 x CANFD
i.MX RT1024 Cortex-M7 @500 MHz 144 LQFP 256 kB SRAM,
4 MB Flash		 - - - 3 x I2S, S/PDIF 1 1 x 10/100 2 x FlexCAN
i.MX RT1020 Cortex-M7 @500 MHz 100 LQFP,
144 LQFP 		256 kB SRAM - - - 3 x I2S, S/PDIF 1 1 x 10/100 2 x FlexCAN
i.MX RT1015 Cortex-M7 @500 MHz 100 LQFP 128 kB SRAM - - - 3 x I2S, S/PDIF 1 - -
i.MX RT1010 Cortex-M7 @500 MHz 80 LQFP 128 kB SRAM - - - 2 x I2S, S/PDIF 1 - -
i.MX RT600 Cortex-M33
@300 MHz + Cadence® Tensilica® HiFi 4 @600 MHz 		176 BGA, 249 FOWLP, 114 CSP 4.5 MB SRAM - - - 8 x I2S
8-ch DMIC		 1 - -
i.MX RT500 Cortex-M33 @275 MHz + Cadence® Tensilica® Fusion F1 @275 MHz 249 FOWLP 5 MB SRAM 2D GPU Parallel, MIPI Parallel 12 x I2S
8-ch DMIC		 1 - -

1. Preproduction Product. This page contains information on a preproduction product. Specifications and information herein are subject to change without notice. For additional information contact support or your sales representative.

Note: Some features vary across families.

Time-Sensitive Networking Solution Bridges Communication Gaps in Industrial IoT

The new i.MX RT1180 includes a Gb Time-Sensitive Networking (TSN) Switch enabling real-time rich networking integration handling both time-sensitive and industrial real-time communication.

Read more
i.MX RT Tech Minute Image

MCU Minutes

Improve your performance and integration with the i.MX RT Crossover MCUs. These short video presentations introduce key features and benefits of NXP MCUs.

White Paper on Crossover Processing

Create Unrivaled IoT Experiences

i.MX RT series of crossover MCUs push the boundaries of what’s possible in the IoT. Connect with your world with ease.

i.MX RT Series

i.MX RT Series

Driving the convergence of applications processors and MCUs.

EdgeReady i.MX RT solutions for Voice Control and Face Recognition

NXP EdgeReady i.MX RT Solutions for Voice Control and
Face Recognition

NXP EdgeReady MCU-based turnkey solutions leverage the i.MX RT Crossover MCUs, enabling developers to quickly and easily add Alexa built-in, local voice commands and face recognition capabilities to their RTOS-based IoT products. These ultra-small form-factor, turnkey hardware and software designs come completely integrated with production ready software, running on FreeRTOS, for easy integration in smart home products, smart appliances and more.

Designing Next-Gen Smart Connected Secure Industrial Drives Just Got Easier

NXP unified the latest Industry 4.0 technologies into a comprehensive hardware and software platform for smart, secure industrial IoT application development. Explore the details.

Find out more

The Empowered Edge - NXP Machine Learning at the Edge

The path to a more intelligent world starts with NXP's advancement of machine learning at the edge. We created a path to accelerate even greater breakthroughs, as machine learning continues to redefine what’s possible through more flexible and robust software platforms and rapid hardware innovations.
