Demoboard for BGU6102, 50 Ω FM low noise amplifier for embedded antenna in portable applications

OM7809

Roll over image to zoom in

The BGU6102 MMIC is an unmatched wideband MMIC featuring an integrated bias, enable function and wide supply voltage range. BGU6102 is part of a family of three products (BGU6101, BGU6102 and BGU6104).

This customer evaluation kits contains one application board for FM band (70 MHz to 130 MHz).

Product Details

Select a section:

Supported Devices

RF

LNAs for General Purpose

  • BGU6102: Wideband Silicon Low-Noise Amplifier MMIC

Features

  • Evaluation of electrical DC and RF performance like IDC, S-Parameters, Distortion levels, P-1dB, Noise Figure
  • PCB layout evaluation
  • Device Models and S-parameters

Buy Options

  • OM7809

  • Demoboard for BGU6102, 50 Ω FM low noise amplifier for embedded antenna in portable applications.

    • 50 Ω assembled application board for 70 MHz to 130 MHz
    • 10 pcs loose samples BGU6102
  • $160.00 USD
  • For a quantity of 1
