88W8964 Wi-Fi® 802.11ac Wave2 Dual-band SoC

Overview

The Avastar 88W8964 features 160MHz bandwidth and Multi-User Multi-Input Multi-Output (MU-MIMO) while achieving 2.6 Gbit/s peak data rate for high speed, secure, and reliable access points and smart gateways. Supporting high-performance 802.11i security standards through implementation of the Advanced Encryption Standard (AES)/Counter Mode CBC-MAC Protocol (CCMP), Wired Equivalent Privacy (WEP) with Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard (AES)/Cipher-Based Message Authentication Code (CMAC) and WLAN Authentication and Privacy Infrastructure (WAPI) security mechanisms, the 88W8964 delivers 802.11e Quality of Service (QoS) to reduce latency for video, voice, and multimedia applications.

Multi-User Mimo Technology

Multi-User MIMO allows simultaneous sessions from one access point to several client devices at the same time. The 88W8964 supports three 1x1 or a mix of 2x2 and 1x1 connections at the same time.

Features

4x4 MIMO Dual-band 802.11ac Wave-2 solution
Multi-User MIMO support: three 1x1 / 2x2 and 1x1 client devices combination
Backward compatible with 802.11a/b/g/n
Channel Bandwidth up to 160, 80, 40 and 20 MHz.
Implicit and explicit transmit Beamforming technology
Integrated Arm^® Dual-Core Cortex^® A9 CPU, internal SRAM
Integrated Spectrum Management 802.11mc for sub-1 meter indoor location

Features

4x4 MIMO Dual-band 802.11ac Wave-2 solution
Multi-User MIMO support: three 1x1 / 2x2 and 1x1 client devices combination
Backward compatible with 802.11a/b/g/n
Channel Bandwidth up to 160, 80, 40 and 20 MHz.
Implicit and explicit transmit Beamforming technology
Integrated Arm^® Dual-Core Cortex^® A9 CPU, internal SRAM
Integrated Spectrum Management 802.11mc for sub-1 meter indoor location

Target Applications

Communication Infrastructure

Enterprise & retail access points and hotspots

Smart Home

Set-top box
Smart Home Gateway

What's New

88W8964: Gigabit Speed, Reliability and Quality for Next-Generation WLAN

The Avastar 88W8964 SoC features 160 MHz bandwidth and multi-user multi-input multi-output (MIMO) while achieving 2.6 Gbit/s peak data rate for high-speed, secure and reliable access points and smart gateways.
