PTN38003A Evaluation Board

PTN38003A-EVM

Roll over image to zoom in

This evaluation board can be use to evaluate PTN38003A redriving USB 3.2 and DisplayPort 1.4 signals over longer channel length, on either motherboard side or on the device side. It optionally can be use to evaluate signal driving capability on an active cable.

Please review the UM11595 User Manual (chapter 4 - Getting to know to the hardware) for the two DFP and UFP options.

Product Details

Select a section:

Supported Devices

Interfaces

High-Speed Signal Conditioners

  • PTN38003A: Type-C USB 3.2 and DisplayPort v 1.4 Combination Linear Redriver

Features

General Features

  • Support USB 3.2 / DisplayPort 1.4 / Thunderbolt 3 / USB4 Interfaces
  • Small form factor
  • Low-power consumption

Buy Options

  • PTN38003A-EVM

  • PTN38003A Evaluation Board.

  • Kit Contains

    • Assembled and tested evaluation board in an anti-static bag
    • Quick start guide
  • $239.25 USD
  • For a quantity of 1
    • Availability: In stock
    • Inventory: 2
    • Shipping: Normally ships 1-2 business days
Buy from NXPBuy From Distributor

Documentation

Quick reference to our documentation types.

Filters

2 documents

Design Resources

Select a section:

Design Files

Filters

2 design files

  • Printed Circuit Boards and Schematics

    PTN38003A-EVM Schematics

    ZIPRev AJul 26, 2021 15:50:00613.0 KBPTN38003A-EVM-SCH
    Download
  • Printed Circuit Boards and Schematics

    PTN38003A-EVM Design files

    ZIPRev AJul 26, 2021 15:57:009.7 MBPTN38003A-EVM-DESIGN-FILES
    Download

Software

Filters

1 software file

  • BSP, Drivers and Middleware

    PTN38007/PTN38003A/PTN3944 Software GUI

    ZIPRev 1.0Sep 24, 2020 12:50:003.3 MBPTN3800X_GUI_SW
    Download

Note: For better experience, software downloads are recommended on desktop.
