PTN38007 Evaluation Board

PTN38007-EVM

Roll over image to zoom in

This evaluation board can be use to evaluate PTN38007 redriving USB 3.2, DisplayPort 2.0, Thunderbolt 3 and USB 4 signals over longer channel length, on either motherboard side, or on the device side. It can also be used to evaluate signal driving capability on an active cable.

Product Details

Select a section:

Supported Devices

Interfaces

High-Speed Signal Conditioners

  • PTN38007: Multiprotocol USB 4 20 Gbps Linear Redriver

Features

General Features

  • Support USB3.2, DisplayPort 2.0, Thunderbolt 3 and USB 4 interfaces
  • Small form factor
  • Low-power consumption

Buy Options

  • PTN38007-EVM

  • PTN38007 Evaluation Board.

  • PTN38007-EVM - DisplayPort linear redriver evaluation board

    • PTN38007-EVM PCB hardware
  • $363.00 USD
  • For a quantity of 1
Buy From Distributor

Documentation

Quick reference to our documentation types.

Filters

2 documents

Design Resources

Select a section:

Design Files

Filters

2 design files

  • Printed Circuit Boards and Schematics

    PTN38007-EVM Schematics

    ZIPRev AJul 26, 2021 16:10:00613.0 KBPTN38007-EVM-SCH
    Download
  • Design Files - miscellaneous

    PTN38007-EVM Design files

    ZIPRev AJul 26, 2021 16:06:009.7 MBPTN38007-EVM-DESIGN-FILES
    Download

Software

Filters

1 software file

  • BSP, Drivers and Middleware

    PTN38007/PTN38003A/PTN3944 Software GUI

    ZIPRev 1.0Sep 24, 2020 12:50:003.3 MBPTN3800X_GUI_SW
    Download
