2450 MHz, 300 W CW, 32 V RF LDMOS Transistor for Consumer and Commercial Cooking

MHT1004N
  • Archived
  • This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.

Roll over image to zoom in

Product Details

Select a section:

RF Performance Tables

Typical Performance

VDD = 32 Vdc, IDQ = 100 mA

Load Mismatch/Ruggedness

Frequency
(MHz)
Signal Type VSWR Pin
(W)
Test
Voltage
Result
2450CW> 5:1
at all Phase Angles
15.0
(2 dB Overdrive)
32No Device Degradation
