- MMRF1024HS
2496-2690 MHz, 50 W Avg., 28 V RF Power LDMOS Transistor
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The MMRF1024HS 50 W asymmetrical Doherty RF power LDMOS transistor is optimized for instantaneous signal bandwidth capabilities covering the frequency range of 2496 to 2690 MHz. This part is ideally suited for commercial and defense communications and electronic warfare applications, such as an IED jammer.
Product Details
RF Performance Table
2600 MHz
Typical Doherty Single-Carrier W-CDMA Performance: VDD = 28 Vdc, IDQA = 700 mA, VGSB = 0.4 Vdc, Pout = 50 W Avg., Input Signal PAR = 9.9 dB @ 0.01% Probability on CCDF.| Frequency | Gps (dB) |
ηD (%) |
Output PAR (dB) |
ACPR (dBc) |
| 2496 MHz | 14.1 | 44.6 | 8.1 | –31.5 |
| 2590 MHz | 14.4 | 44.9 | 8.1 | –33.8 |
| 2690 MHz | 14.2 | 44.2 | 7.9 | –37.6 |
