- No Longer Manufactured
- MPXx12
Differential and Gauge, Uncompensated Pressure Sensor (0 to 10 kPa)
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The MPX12 series pressure sensors for medical and industrial applications deliver silicon piezoresistive devices with very accurate and linear voltage output, directly proportional to the applied pressure.
- Provides standard, cost-effective, uncompensated sensors
- Allows you to add your own external temperature compensation and signal conditioning networks to designs
- Simplifies compensation techniques because of the predictability of NXP’s single element strain gauge design
Product Details
Features
Key Features
- Cost-effective
- Silicon shear stress strain gauge design
- Ratiometric to supply voltage
- Easy-to-use chip carrier package options
- Differential and gauge options
- Durable epoxy package
