Half bridge control IC for CCFL backlighting

For best experience this site requires Javascript to be enabled. To enable on your browser, follow our accessibility instructions.

No Longer Manufactured
UBA2071AT

Roll over image to zoom in

The UBA2071 and UBA2071A are high voltage ICs intended to drive Cold Cathode Fluorescent Lamps (CCFLs) or External Electrode Fluorescent Lamps (EEFLs) for backlighting applications. They can drive a half bridge circuit made up of two NMOSFETs with a supply voltage of up to 550 V, so the inverter can be supplied directly from a 400 V PFC bus.

Data Sheet

Documentation

Quick reference to our documentation types.

3 documents

^{Data Sheet}
Half bridge control IC for CCFL backlighting

PDFRev 1.0Jun 23, 2008574.0 KBUBA2071_AEnglish
^{Package Information}
plastic small outline package; 24 leads; body width 7.5 mm

PDFRev 1.0Feb 8, 2016388.2 KBSOT137-1English
^{Packing Information}
SO24; Reel pack; SMD, 13" Q1/T1 Standard product orientation Orderable part number ending ,118 or J Ordering code (12NC) ending 118

PDFRev 4.0Apr 12, 2013240.7 KBSOT137-1_118English
