1 GHz 12 dB Gain Wideband Amplifier MMIC

BGA3012

The BGA3012 MMIC is a wideband amplifier with internal biasing. It is designed specifically for high linearity CATV line extenders and drop amplifiers over a frequency range of 5 MHz to 1006 MHz. The LNA is housed in a lead free 3-pin SOT89 package.

See product image

Product Details

Select a section:

Features

  • Internally biased
  • Flat gain
  • High linearity with an IP3O of 40 dBm and an IP2O of 60 dBm
  • Noise figure of 3.1 dB
  • 75 Ω input and output impedance
  • Operating from 5 V to 8 V supply

Target Applications

  • General wideband amplifiers
  • CATV return amplifier; frequency ranges of 5 MHz to 300 MHz
  • CATV infrastructure network driver in optical nodes (FTTx), distribution amplifiers, trunk amplifiers and line extenders in the frequency range from 40 MHz to 1006 MHz
  • The product is ideally suited for applications as drop amplifiers in CATV distribution systems such as FTTH
