PCF85063TP-ARD Arduino® Shield Evaluation Board

PCF85063TP-ARD

Roll over image to zoom in

The PCF85063TP Arduino® Shield features most of RTC functionalities on a board compatible with Arduino R3 pin layout. A graphical interface allows the user to easily explore the different functions of the RTC. Moreover, embedded driver and demo application can be found as reference code to quick start.

Product Details

Select a section:

Supported Devices

Peripherals and Logic

RTCs with I2C-bus

Features

General Features

  • Connector for external access to I2C-bus
  • On-board LED for interrupt pin monitoring
  • Equipped with Arduino Uno R3 port for direct connection with Arduino devices
  • Fully compliant with IMXRT1050 EVK board
  • Fully compliant with LPCXpresso55S69 dev. board
  • Compliant with i.MX Mini LPDDR4 EVK board

Buy Options

PCF85063TP-ARD-Image

Click to expand

  • PCF85063TP-ARD

  • PCF85063TP-ARD Arduino® Shield Evaluation Board.

  • Kit contains:

    • Assembled and tested evaluation board in an anti-static bag
    • Quick Start Guide
  • $97.35 USD
  • For a quantity of 1
    • Availability: In stock
    • Inventory: 10
    • Shipping: Normally ships 1-2 business days
