- No Longer Manufactured
- OM7800
Low-noise amplifier evaluation board with BGU7003 for 2.4 GHz ISM/WLAN
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The BGU7003 LNA evaluation board simplifies the evaluation of the BGU7003 LNA for the 100 MHz FM application. The evaluation board enables testing of the device performance and requires no additional support circuitry. The board is fully assembled with the BGU7003, including the input and output matching circuitry as well as a decoupling capacitors to optimize the performance. The board is supplied with two SMA connectors for input and output connection to RF test equipment. The BGU7003 board is optimized for 2.8 V operation and consumes about 5 mA.
Product Details
Supported Devices
Products
No Longer Manufactured
- BGU7003: Wideband silicon germanium low noise amplifier MMIC
Features
Connectivity
- Two SMA connectors for input and output connection to RF test equipment
Power Management
- Evaluation of the power on settling time ton and the power off settling time toff
Target Applications
- FM applications, like portable audio devices and mobile computing devices like feature phones, tablet PC's and notebook PC's.
