BGU7003: Wideband silicon germanium low noise amplifier MMIC ARCHIVED

• Low noise high gain microwave MMIC
• Applicable between 40 MHz and 6 GHz
• Integrated temperature stabilized bias for easy design
• Bias current configurable with external resistor
• Noise figure NF = 0.80 dB at 1.575 GHz
• Insertion power gain = 18.3 dB at 1.575 GHz
• 110 GHz transit frequency - SiGe:C technology
• Power-down mode current consumption < 1 μA
• Optimized performance at low supply current of 5 mA
• ESD protection > 1 kV Human Body Model (HBM) on all pins

Target Applications

• GPS
• Satellite radio
• Low-noise amplifiers for microwave communications systems
• WLAN and CDMA applications
• Analog and digital cordless applications
