Transport Ticketing
NXP offers fast and secure solutions for access to, and payment in, public transport. These range from smart cards and ticket ICs to mobile and wearable applications.
Our secure RAIN RFID ICs support hands-free access in public transport, which makes it easier to get around without having to tap a card or ticket to a reader.
Transport barrier systems can validate tickets and also take contactless payment from credit cards and mobile phones. These systems maintain a database of all transactions including a local copy kept in the machine and a copy uploaded to a central database.
Application Details
Interactive Block Diagram
Interactive Block Diagram
For the best experience interacting with diagrams, please use a larger screen or maximize your browser window.
Select a block diagram:
Block Diagram
- Transport Ticketing
MPU
-
i.MX6ULL:
i.MX 6ULL Single-Core Processor with Arm® Cortex®-A7 Core
Contact Readers
-
TDA8035HN:
High-Integrated and Low-Power Smart Card Interface
RTC W/Battery
-
PCF85263A:
Tiny Real-Time Clock/Calendar with Alarm Function, Battery Switch-Over, Time Stamp Input and I²C-Bus
TAG
-
MC_57609:
MIFARE Plus -
MC_53450:
MIFARE DESFire -
SL3S5002N0FUD:
UCODE® DNA: UHF Tag IC for Secure Authentication
Readers
-
PN5180:
Full NFC Forum-Compliant Frontend IC
Temperature Sensor
-
PCF85263A:
Tiny Real-Time Clock/Calendar with Alarm Function, Battery Switch-Over, Time Stamp Input and I²C-Bus -
P3T2030xUK:
I3C, I²C-Bus, 2.0 °C Accuracy, Digital Temperature Sensor -
P3T1035xUK:
I3C, I²C-Bus, ±0.5 °C Accuracy, Digital Temperature Sensor
PMIC
Customize
Block Diagram Designer*
Learn how to customize interactive diagrams with ease. Ready to jump in? Explore an overview or select an editable block diagram from above to start a project.
Documentation
Quick reference to our documentation types
5 documents
Application Note (2)
Brochure (1)
-
MIFARE 2GO leaflet[MIFARE-2GO-LEAFLET]
Fact Sheet (1)
-
NXP® MIFARE® DESFire® Light[MIFAREDFLLIGHT]
