Digital Key Reference System (CCC / ICCE / ICCOA)

DIGITAL-KEY-RD

Roll over image to zoom in

This automotive smart access reference design combines Bluetooth® for pre-ranging and wake-up (with upcoming Bluetooth channel sounding support) with secure ultra-wideband (UWB) for precise ranging and localization. By leveraging both technologies, it delivers secure, accurate and seamless keyless entry. Fixed anchors in a vehicle work in tandem with a remote device—such as a key fob—to authenticate user proximity with centimeter-level accuracy.

By being compliant with the Car Connectivity Consortium (CCC) Digital Key Release 4.0  and supporting variants such as the Intelligent Car Connectivity Industry Ecosystem Alliance (ICCE) and the Intelligent Car Connectivity Open Alliance (ICCOA), this design provides a robust, relay-resistant solution that enhances both convenience and security for the digital automotive access system.

Block Diagram

Digital Key Reference Design

Digital Key Reference Design
Get diagram PDF

Supported Devices

Wireless Connectivity

Trimension® UWB

  • NCJ29D6: Trimension® NCJ29D6: Secure UWB IC for Automotive Ranging and Radar Applications

Bluetooth Low Energy

  • KW45: KW45: 32-Bit Bluetooth® 6.0 Long-Range MCUs with CAN FD and LIN Bus Options, Arm® Cortex®-M33 Core

Features

UWB Secure and Precise Ranging

  • Enables centimeter-level accuracy and helps prevent relay attacks with physical layer security (PLS)

CCC Support

  • Supports CCC's Digital Key 4.0

ICCE/ICCOA Enablement

  • Supports local variants of digital key standards

Multi-Technology Support

  • Full system design including:
    • Bluetooth Low Energy (BLE) for low-power communication and wake-up
    • UWB for secure and precise localization
    • NFC for pairing and access support

Security

  • Robust anti-relay and anti-spoofing mechanisms based on UWB secure ranging, supported by a secure element to protect the vehicle access information with physical and electrical attack resistance

Spatial Awareness

  • Utilizes localization algorithms for seamless passive entry, exit and passive start

Radar Enablement (Coming Soon)

  • The anchor points can stream data to implement UWB radar applications

Buy Options

LID2506-Image

Click to expand

LID2506
Active

Omnidirectional Antenna Board for UWB Applications.

    $39.00 USD
    In Stock :49

    Normally ships 1-2 business days

    ADD TO CART
    KW45B41Z-EVK-Image

    Click to expand

    KW45B41Z-EVK
    Active

    KW45B41Z Evaluation Kit with Bluetooth® Low Energy.

      $129.00 USD
      Pending Stock
      ADD TO CART
      Order from distributors
      LID2580-NCJ29D6-Image

      Click to expand

      LID2580-NCJ29D6
      Active

      Digital Key Reference System (CCC / ICCE / ICCOA).

        $149.00 USD
        Pending Stock
        ADD TO CART
        Order from distributors
        KW45B41Z-LOC-Image

        Click to expand

        KW45B41Z-LOC
        Active

        Localization Reference Design.

          Order from distributors
