SiGe:C Low Noise Amplifier MMIC for GPS, GLONASS, Galileo and Compass

See product image

Product Details

Select a section:

Features

  • Covers full GNSS L1 band, from 1559 MHz to 1610 MHz and LTE band 32 from 1452MHz to 1496 MHz
  • GNSS
    • Noise figure = 0.65 dB
    • Gain 18 dB
    • High input 1 dB compression point of ‒7 dBm
    • High out of band IP3i of 6 dBm
  • LTE B32
    • Noise figure = 0.65 dB
    • Gain 20 dB
    • High input 1 dB compression point of -8.5 dBm
  • Supply voltage 1.5 V to 3.1 V
  • Optimized performance at very low supply current of 4.2 mA
  • Power-down mode current consumption < 1 μA
  • Integrated temperature stabilized bias for easy design
  • Requires only one input matching inductor and one supply decoupling capacitor
  • Input and output DC decoupled
  • ESD protection on all pins (HBM > 2 kV)
  • Integrated matching for the output
  • Available in a 6-pins leadless package 1.1 mm x 0.9 mm x 0.47 mm; 0.4 mm pitch: SOT1230
  • 180 GHz transit frequency - SiGe:C technology
  • Moisture sensitivity level 1

Target Applications

  • Smart phones
  • Feature phones
  • Tablets
  • Digital still cameras
  • Digital video cameras
  • RF front-end modules
  • Complete GNSS modules
  • Personal health applications

Part numbers include: BGU8009.
