ColdFire MCF51MM Medical Development Tower System Module

TWR-MCF51MM Preproduction

Roll over image to zoom in

The TWR-MCF51MM module is a development board for the NXP® MCF51MM256 Flexis® ColdFire® 32-bit MCUs.

  • Designed to aid in the evaluation and prototyping of medical applications, it includes an electrocardiograph sensor (MED-EKG) as part of the evaluation system
  • The TWR-MCF51MM operates as a standalone debug tool and can also be combined and used as part of the modular Tower® System development platform

Supported Devices

Processors and Microcontrollers

ColdFire® V1 Processors

  • MCF51MM: Flexis 32-Bit ColdFire® V1 MCUs

8-Bit S08 MCUs

  • S08MM: 8-bit Flexis USB MM128/64/32 MCUs

Features

Connectivity

  • Two 80-pin connectors on the outside to support debugging or expansion to LCD module
  • RS-232, RS485, CAN, USB
  • Open connector for MED-EKG development board

Power Management

  • Includes power regulation circuitry with standardized bus
  • Low power

Debug

  • Integrated open source BDM debugging tool

Size

  • small form factor

Support

  • Supports external communications interfaces
  • The TWR-MCF51MM board contains a Flexis® MCF51MM256, an Energy-Efficient Product Solution by NXP®
