Join our teamTWR-12311: Sub-1GHz Smart Radio Tower® System Module
TWR-12311 Block Diagram
Specifications
Technical and Functional Specifications
Hardware Features
- MC12311 sub-1 GHz SiP operating from 315 MHz to 960 MHz
- Programmable 32 KB flash memory and 2 KB RAM
- Antennas with SMA connectors
- Power amplifier output
- Unbalance input/output port
- Flexible RF-front end for different bands operation
- Programmable output power from -18 dBm to +17 dBm in 1 dB steps
- High sensitivity: down to -120dBm at 1.2 kbps
- Onboard background debug module (BDM) port for MCU flash reprogramming and in-circuit hardware debugging
- USB port to interface with PC
- LEDs and switches for demonstration, monitoring and control
Software Features
- Our MC12311 simple media access controller (SMAC) is a simple ANSI C-based code stack available as sample source code. It is used for developing proprietary RF wireless applications using a sub-1 GHz transceiver. The MC12311 SMAC was built to enable the flexibility of the MC12311 integrated circuit (IC). The MC12311 SMAC is incorporated into the BeeKit® Wireless Connectivity Toolkit, which makes it easier for users to employ and customize MC12311 SMAC
- Our MC12311 radio utility application provides a way to interact with the transceiver based on SMAC embedded applications. The radio utility application allows for complete configuration of the radio as well as basic transmitter and receiver tests
- IEEE® 802.15.4 MAC with custom PHY layer: NXP® has developed a subset of the 802.15.4 PHY/MAC that fits into the internal flash memory of the MC12311. It supports the G-FSK modulation with multiple frequencies, data rates and channels
- NXP provides support for wireless M-Bus through our partner AMiHO. NXP provides an evaluation version of wireless M-Bus and a full version can be purchased through AMiHO
Supported Devices
Documents and Software
Documents ( 3 )
Design Resources ( 1 )
Software ( 3 )
Documents
Reference Manual ( 2 )
-
MC12311 Development Hardware Reference Manual (REV 0 )
This manual describes NXP’s 12311-MRB development platform hardware. The MC12311 development platform is a highly-integrated, cost-effective, system-in-package (SIP), sub-1GHz wireless node solution with an FSK, GFSK, MSK, or OOK modulation-capable transceiver and low-power QE32 8-bit microcontroller. The highly integrated RF transceiver operates over a wide frequency range including 315 MHz, 433 MHz, 470 MHz, 868 MHz, 915 MHz, 928 MHz, and 955 MHz in the license-free Industrial, Scientific and
-
TWR-RF Module - Reference Manual (REV 4 )
The TWR-RF is a Tower® Controller Module compatible with the Tower System. It can function as a stand-alone, low-cost platform for the evaluation of Our wireless mounted on the appropriate Modular Reference Board (MRB).
Quick Reference Guide ( 1 )
-
TWR-RF-MRB Quick Start Guide (REV 0 )
Tower® interface board for 1323x-MRB and 12311-MRB boards
Design Resources
Design Tools & Files ( 1 )
Printed Circuit Boards and Schematics ( 1 )
-
MC1231x MRB files (REV A2 )
The MC12311 development platform is a highly-integrated, cost-effective, system-in-package (SIP), sub-1GHz wireless node solution with an FSK, GFSK, MSK, or OOK modulation-capable transceiver and low-power QE32 8-bit microcontroller.
