The S12G is an optimized, 16-bit microcontroller product line focused on low cost, high performance and low pin count. The S12G is suited for generic automotive and industrial applications requiring CAN or LIN/SAE J2602 communication.

The S12G delivers all the advantages and efficiencies of a 16-bit MCU while retaining the cost effectiveness, power consumption, EMC and code-size efficiency advantages currently enjoyed by users of our existing 8-bit and 16-bit MCU families.

Data Sheet

Reference Manual

Product Details

Block Diagram

S12G Microcontroller Block Diagram

Get diagram PDF

Features

S12 CPU core, 25 MHz bus
Up to 240 KB on-chip flash with ECC
Up to 4 KB EEPROM with ECC
Up to 11 KB on-chip SRAM
Up to one multi-scalable controller area network (MSCAN) module
- Supporting CAN protocol 2.0 A/B
Up to three serial communication interface (SCI) modules
- Supporting LIN communications
Up to three serial peripheral interface (SPI) modules
Precision fixed voltage reference for analog-to-digital conversion (ADC)
1 MHz internal oscillator
On-chip voltage regulator for input supply and internal voltages
This product is included in NXP^® product longevity program, with assured supply for a minimum of 15 years after launch

S12G Family Comparison table

	EEPROM	Internal RAM	Internal Flash	Serial Interface Type	16-bit Timers	ADC Bits/Channels	Package Description
S12GN16	0.5 KB	1 KB	16 KB	SCI SPI	Timer Channels: 6 Number of Timers: 1	10	LQFP 32 771.4P0.8 LQFP 48 771.4P0.5
S12GN32	1 KB	2 KB	32 KB	SCI SPI	Timer Channels: 6 Number of Timers: 1	10	LQFP 32 771.4P0.8 QFN-EP 48 7.0SQ1.0P0.5 LQFP 48 77*1.4P0.5
S12G48	1.5 KB	4 KB	48 KB	CAN SCI SPI	Timer Channels: 6 Number of Timers: 1	10	LQFP 32 771.4P0.8 LQFP 64 10101.4P0.5 LQFP 48 771.4P0.5
S12G64	2 KB	4 KB	64 KB	CAN SCI SPI	Timer Channels: 6 Number of Timers: 1	10	LQFP 48 771.4P0.5 LQFP 64 10101.4P0.5 LQFP 32 771.4P0.8
S12G96	3 KB 4 KB	8 KB	96 KB	CAN SCI SPI	Timer Channels: 8 Number of Timers: 1	10	LQFP 64 10101.4P0.5 LQFP 48 771.4P0.5 LQFP 100 14141.4P0.5
S12G128	4 KB	8 KB	128 KB	CAN SCI SPI	Timer Channels: 8 Number of Timers: 1	10	LQFP 64 10101.4P0.5 LQFP 100 14141.4P0.5 LQFP 48 771.4P0.5
S12G192	4 KB	12 KB	192 KB	CAN SCI SPI	Timer Channels: 8 Number of Timers: 1	10 12	LQFP 64 10101.4P0.5 LQFP 48 771.4P0.5 LQFP 100 14141.4P0.5
S12G240	4 KB	12 KB 11 KB	240 KB	CAN SCI SPI	Timer Channels: 8 Number of Timers: 1	12 10	LQFP 64 10101.4P0.5 LQFP 48 771.4P0.5 LQFP 100 14141.4P0.5
