Electricity Meter
NXP® metering technology enables one-phase, two-phase, and three-phase electricity meters used for measurement and registration of active, reactive, and apparent energy in residential and commercial metering applications. Along with its connectivity solutions for smart metering – like IEEE 802.15.4, ZigBee and Bluetooth Low Energy - NXP addresses the challenges smart cities face for reliable, secure communications for remote metering and home energy management.
Application Details
Block Diagram
Recommended Products for:
Electricity Meter
Select a block to see our recommended products.
MCU
- KM3x: 50–75 MHz Precision Metrology MCUs with Segment LCDs based on Arm® Cortex®-M0+
Sensors
- MMA8491Q: ±8g, Low g, Digital NXP® Accelerometer
- FXOS8700CQ: Digital Motion Sensor - 3D Accelerometer (±2g/±4g/±8g) + 3D Magnetometer
Sensors
- MMA8491Q: ±8g, Low g, Digital NXP® Accelerometer
- FXOS8700CQ: Digital Motion Sensor - 3D Accelerometer (±2g/±4g/±8g) + 3D Magnetometer
Security (EdgeLock Discrete)
Zigbee
- JN5169: ZigBee and IEEE802.15.4 Wireless Microcontroller with 512 kB Flash, 32 kB RAM
NFC
- PN5180: Full NFC Forum-Compliant Frontend IC
Power Management
- TEA1721AT: HV Start-Up Flyback Controller with Integrated MOSFET for 5 W Applications, F~burst = 430 Hz
Wireless Platform
RTC
- PCF2131: Nano-Power Highly Accurate RTC with Integrated Quartz Crystal
Designs
Reference Design
Single-Phase Metering
Addresses accuracy and cost needs by providing a high-performance analog front end combined with an embedded programmable gain amplifier.
Reference Design
Two Phase Power Meter
Increases the accuracy of energy measurement by providing a high-performance analog front end combined with an embedded programmable gain amplifier.
Reference Design
Three-Phase Power Meter
Used for measurement and registration of active and reactive energy in three-phase networks for direct connection.
