Augmented Reality and Virtual Reality Headsets
Overview
Specifications
Choose a diagram
Augmented Reality Block Diagram
Accelerometers
- MMA8652FC : ±2g/±4g/±8g, Low g, 12-Bit Digital Accelerometer
- MMA8451Q : ±2g/±4g/±8g, Low g, 14-bit Digital Accelerometer
6-Axis Sensor
- FXOS8700CQ : Digital Motion Sensor - 3D Accelerometer (±2g/±4g/±8g) + 3D Magnetometer
Pressure Sensors
- MPL3115A2 : 20 to 110 kPa, Absolute Digital Pressure Sensor
Intelligent Sensing Hub
- MMA8451Q : ±2g/±4g/±8g, Low g, 14-bit Digital Accelerometer
MPU
- i.MX6D : i.MX 6Dual Processors - Dual-Core, 3D Graphics, HD Video, Multimedia, Arm® Cortex®-A9 Core
- i.MX6Q : i.MX 6Quad Processors - High-Performance, 3D Graphics, HD Video, Arm® Cortex®-A9 Core
- i.MX6DP : i.MX 6DualPlus Processor - Dual-Core, High-Performance, Advanced 3D Graphics, HD Video, Advanced Multimedia, Arm® Cortex®-A9 Core
- i.MX 8M Mini - Arm® Cortex®-A53, Cortex-M4, Audio, Voice, Video
Audio Codec
- SGTL5000 : Ultra-Low-Power Audio Codec
Power Management
- PF8121 : 12-channel Power Management Integrated Circuit (PMIC) for High-performance Consumer Applications
- MMPF0100 : 14-Channel Configurable PMIC
Wi-Fi
- IW416: 2.4/5 GHz Dual-Band 1x1 Wi-Fi® 4 (802.11n) + Bluetooth® 5.1 Solution
- 88W8987 : 2.4/5 GHz Dual-Band 1x1 Wi-Fi® 5 (802.11ac) + Bluetooth® 5.2 Solution
- 88MW32X 802.11n Wi-Fi® Microcontroller SoC
Augmented Reality Block Diagram
Documents ( 1 )
Documents
Brochure ( 1 )
-
Smart, Battery-Friendly Solutions for Wearables and Personal Devices – Brochure
Despite the popularity of body-worn wearables such as fitness trackers and smartwatches, manufacturers are expanding the scope to include any portable device we interact with including smart patches and smart clothing. Discreet and nearly invisible personal devices will encourage acceptance by reluctant users who want to avoid calling attention to a disability or medical need.
