EtherNet/IP Industrial Ethernet Protocol Software
EtherNet/IP is an industrial Ethernet protocol that implements the Common Industrial Protocol (CIP) over Ethernet, using IP, TCP and UDP. In an EtherNet/IP network, the “Scanner” serves as the controller and typically initiates requests, while the “Adapter” is a device that responds to those requests. NXP provides EtherNet/IP Adapter protocol software for select NXP SoCs as part of a suite of robust, certifiable industrial Ethernet protocols built on a common software architecture. EtherNet/IP is often used with the Device Level Ring (DLR) resilience protocol and NXP’s EtherNet/IP software supports DLR Beacon-based Ring Nodes.
Software Details
Diagram
Features
Encapsulation Protocol
- Encapsulates CIP messages on EtherNet/IP networks
- Defines header, address items and data items
- Provides commands for device identification, session management and message transport
- Sessions correspond to TCP connections between endpoints
CIP Object Model
- Organizes functionality into classes with unique class IDs
- ODVA manages official classes; add custom classes
- Objects are instances of classes with their own attributes; services are shared
- CIP addressing uses class ID, instance ID, service ID and optionally attribute ID
CIP Messages
- Explicit Messages
- Implicit Messages
CIP Connections
- Transport Class 3 Connections
- Transport Class 0 & 1 Connections
- Connection Timing
- Production Triggers
- Application Connection Types for Implicit Messages
- Real time formats for Implicit Messages
