MC68HC05SR3 is a member of Our M68HC05 family of cost-effective single-chip microcontrollers. This 8-bit microcontroller unit (MCU) contains on-chip oscillator, CPU, RAM, ROM, I/O, timer, and analog-to-digital converter (ADC). The MC68HC05SR3 is pin compatible with the MC6805R3 and is provided as a low-power upgrade path for MC6805R3 applications. The low-power advantage of CMOS is combined with the addition of I/O and port modifications that help eliminate external components in cost-sensitive applications. The MC68HC705SR3 is available in windowed and OTP packages. All references to the MC68HC05SR3 apply equally to the MC68HC705SR3, unless otherwise stated.
Archived content is no longer updated and is made available for historical reference only.
