SD6 Programmable Driver for Solenoid Control

MC33816

Roll over image to zoom in

The NXP® MC33816 is a programmable gate driver IC for precision solenoid control applications.

  • The IC consists of five external MOSFET high-side pre-drivers and seven external MOSFET low-side pre-drivers
  • Provides a flexible solution for MOSFET gate drive with a versatile control and optimized latency time
  • Gate drive, diagnosis, and protection are managed through four independent microcores, two code RAM and two data RAM banks
  • The IC contains two internal voltage regulators

View internal diagram

Product Details

Select a section:

Block Diagram

MC33816 System Diagram

MC33816 System Diagram
Get diagram PDF

Features

Key Features

  • Battery voltage range, 5.0 V < VBATT < 32 V
  • Pre-drive operating voltage up to 72 V
  • High-side/ low-side pre-drive PWM capability up to 100 KHz (30 nCoulomb)
  • All pre-drivers have four selectable slew rates
  • Eight selectable, pre-defined VDS monitoring thresholds
  • Encryption for microcode protection

Product Longevity Program

  • This product is included in the NXP Product Longevity Program ensuring a stable supply of products for your embedded designs. The MC33816 is included in the 15-year program
