BGA6130 Medium Power Amplifier Evaluation Kit

OM7828 Active

Roll over image to zoom in

The BGA6130 medium power amplifier kit simplifies the evaluation of the BGA6130 medium power amplifier. It contains two RF boards matched to 50 Ohm for two Industrial, Scientific and Medical frequency bands: 434 MHz and 915 MHz. The boards operate at 3.6 V and consume 70 mA. A spare printed-circuit board and SMA connectors are included. This can be used for implementing custom designed matching circuitry for example designed using our device models included in this kit on a USB flash drive. The kit also provides BGA6130 samples for prototyping and product documentation.

Supported Devices

RF

Medium Power Amplifiers

  • BGA6130: 400 MHz to 2700 MHz 1 W High-Efficiency Silicon Amplifier

Features

Key Features

  • Bread board for custom designs
  • Samples for prototyping
  • Device Models and S-parameters
  • Out of the box evaluation of the fully populated RF board for ISM 434 MHz and ISM 915 MHz

Buy Options

OM7828-Image

Click to expand

  • OM7828

  • BGA6130 medium power amplifier evaluation kit.

    • RF board matched for ISM 434 MHz
    • RF board matched for ISM 915 MHz
    • Unpopulated PCB
    • 2 SMA connectors
    • BGA6130 samples
    • USB flash drive containing: user manual, device models, Gerber files, datasheet, etc
  • $160.00USD
  • For a quantity of 1
