Advanced High Voltage Isolated Gate Driver with Segmented Drive for SiC MOSFETs
GD3160 silicon and enablement (documentation, software and boards) are available for selected customers (NDA required). For additional information and sample availability contact support or your local sales representative.
The GD3160 is a galvanically isolated single-channel gate driver designed for driving and protecting SiC MOSFET and IGBT power modules in automotive traction inverter applications.
The GD3160 provides SPI-programmable gate drive control, protection features, diagnostics and fault reporting, enabling optimization of power device performance and system protection. Developed in compliance with ISO 26262, the GD3160 integrates functional safety features that support applications up to ASIL D.
Its high level of integration helps simplify inverter designs while supporting efficient and reliable xEV power conversion systems.
Product Details
Block Diagram
Features
Key Features
- HV isolated IGBT and SiC single gate driver IC device functions
- Load current(IL) 15 A (Typ)
- Single channel
- Drain-to-source on resistance 500 mOhm RDS(ON) (Typ)
- Load supply voltage min. -12 V, max. 25 V
- Supply voltage min. 4.5 V, max. 40 V
- Ambient operating temperature -40 to 125 °C
- PWM and SPI interface and input controllers
Operation
- ±15 A split output gate current drive
- Programmable HV VCC regulator output: 14 V to 21 V, 1 V step
- Max VCC output voltage: 23 V
Protection
- Integrated HV temperature sensing (TSENSE) for NTC thermistor or diode sensors with programmable offset and gain
- Faster VCE DeSat detection and reaction time: < 1.2 µs (SiC)
- Improved PWM deadtime range for reduced switching losses (SiC)
- Programmable two-level turn off (2LTO) and soft-shutdown (SSD)
Functional Safety
- Additional programmable fault pin (INTA)
- Integrated HV fault management (FSISO)
- Programmable VCE output monitoring
Insulation / Isolation
- Minimum common mode transient immunity (CMTI) > 100 V/ns
- 5,000 Vrms galvanic isolation per UL1577 (planned)
