I don’t have a home security system, but my second hand experience from
family and friends is that they can be a real hassle. In addition to the cost
of the system and having it physically installed, there are constant headaches
with remembering to set the alarm, false alarms and having to remember yet
another password. When deciding to bring such a device into the home, home
owners must balance cost and inconvenience with the benefits of peace of mind
and crime deterrence. In the embedded world, as more “Things”
get connected, a similar choice has to be made: accessibility via connectivity
has opened up a new range of “Things” which are vulnerable to
attacks. Embedded developers of home automation nodes, energy metering and
payment solutions all have to deal with numerous and aggressive threats.
As a Kinetis MCU product marketer, I have had the opportunity to collaborate
with security experts from across the company who work on our numerous product
lines to ensure that the best possible security is being implemented in our
embedded solutions. Kinetis MCUs contain features to help improve reliance of
end applications and have a type of embedded trust architecture that can be
used to provide security in the age of increasing connectedness.
Kinetis devices provide an advantage that most other higher end applications
processors do not typically have. Kinetis MCUs are architected to only boot up
from internal memory. This protects against the threat of hijacking an
embedded application by changing an external memory device.
In addition, Kinetis devices have several levels of embedded protection that
can be selected using non-volatile control bits. The protection, when enabled,
restricts access to all internal resources (Flash, SRAM and peripheral
registers) from the debug port. As well, to facilitate a safe firmware update
via a serial peripheral, Kinetis devices have a 64-bit key, which can be set
so that only authorized firmware updates are allowed.
The highest levels of Kinetis security can also lock the embedded memory by
disabling Flash erase capabilities, forever locking the application code in
the end device. This security level creates a secure ‘Read Only
Memory’ version of the embedded application, essentially avoiding the
threat of cloning of a device.
Some Kinetis devices have an additional external memory interface (for SRAM or
NOR Flash). On these devices, when security is enabled, the attributes of this
external memory are controlled by system level configuration bits. So, even in
higher end embedded applications which rely on external memory expansion, the
reliable Kinetis MCU security architecture has the capability of restricting
execution from the external memory to protect against attacks.
Many Kinetis devices also contain a system level Memory Protection Unit (MPU).
This peripheral can be used to define memory spaces with certain access
rights, creating another layer of system checking to ensure that the execution
of firmware is controlled.
Besides the standard features mentioned above, cryptographic acceleration
hardware is available on a number of Kinetis sub-families. This hardware,
which is enabled by
a library, greatly speeds up cryptographic algorithms that can be used in firmware
updates or in the protection of data as it passes from device to device.
On a sub-set of Kinetis devices there are advanced anti-tamper capabilities.
The features of this peripheral include a tamper protected memory space for a
key. The security of a system depends on keeping the Leader key a
secret. The tamper protected memory space is automatically erased if a tamper
event is detected. This erasure of the Leader key happens without any software
intervention, and so can be depended upon to protect the most sensitive data.
Tamper events are not only physical attacks, and so the advanced security
peripheral also protects against temperature, voltage or clock speed attacks.
One of the newest features on the Kinetis devices is the Flash Access Control
(FAC). This feature was made to support the growing need of protection of
software intellectual property (for example, proprietary sensor algorithms, or
connectivity stacks). The FAC allows the use of software libraries while not
allowing them to be read or downloaded from the device. This feature works in
conjunction with the embedded security levels of the Kinetis MCUs to provide
developers a platform to use to promote their innovations in a safe and
reliable way. Being able to protect software property will be a key enabler to
the propagation of embedded technology expected by the Internet of Things.
What will the future bring in regards to embedded security features? To
support the expansion of Kinetis edge nodes, more advanced encryption
acceleration and new algorithms are on the roadmap.
Finally, as a product definer, I am always looking for new requirements. What
aspect of embedded security threat are you concerned with? Leave a comment.
