As an engineer supporting other engineers, I know the struggles of embedded
graphical user interface (GUI) design. This article explores how GUI Guider
helped my customers and I simplify development, reduce errors and deliver
polished UIs faster—with a tool built for real-world embedded needs.
As a systems engineer with over seven years in embedded development—and
several years supporting customers with GUI design—I've seen firsthand how
challenging it can be to build GUIs for embedded systems. From memory
constraints to integration headaches, GUI development has often been one of
the most time-consuming and error-prone parts of a project.
That was true for me, too—until I started using GUI Guider.
The Early Days: Coding GUIs the Hard Way
Back when I first started working with GUIs, building them meant writing
everything from scratch. I'd spend hours manually coding widgets, handling
screen redraws and debugging touch input. Every small change required
recompiling and flashing the board. It was slow, repetitive and frustrating,
especially when supporting customers who needed fast turnarounds.
Even with powerful microcontrollers (MCUs), the lack of a streamlined GUI
workflow often became a bottleneck.
Discovering GUI Guider
When NXP released GUI Guider, I was immediately intrigued, especially because
this was a free tool developed by NXP. GUI Guider is a visual design tool
built on Light and Versatile Graphics Library (LVGL), with support for NXP's
full range of edge processors. It sounded promising and it delivered.
I started using it for internal projects, then began recommending it to
customers. The results were consistent: faster development, cleaner code and
happier teams.
Engineer and streamline your graphical user interface.
Explore
GUI Guider
and start building smarter GUIs today.
GUI Guider: 5 Reasons Your Interface Design Just Got Way Easier.
Visual Design That Speaks Developer
GUI Guider's drag and drop visual interface eliminated the need for repetitive
coding, streamlining the entire GUI development process. Instead of writing
boilerplate code for buttons, sliders and charts, I could:
- Design screens visually
- Customize styles and animations
- Preview everything in real time
This was especially helpful when working with customers who weren't embedded
experts as they could contribute to the UI design without touching a line of
code.
Seamless Integration with Embedded Projects
One of GUI Guider's greatest strengths is how well it integrates with NXP's
toolchain. It generates LVGL-based C code that plugs directly into:
- MCUXpresso for Visual Studio (VS) Code
- MCUXpresso Integrated Development Environment (IDE)
- IAR Embedded Workbench
- Keil
- GNU compiler collection (GCC)-based workflows
Moreover, it supports custom code injection, so I could add logic without
worrying about it being overwritten during updates.
Built for Real-World Constraints
As someone who's worked on everything from industrial controllers to consumer
devices, I appreciate how GUI Guider is optimized for embedded systems:
- Lightweight code generation
- Image conversion with dithering and stride alignment
- GPU acceleration via VGLite on supported platforms
It's not just about making GUIs look good—it's about making them run
efficiently on real hardware.
Final Thoughts: Why I Recommend GUI Guider
Over the years, I've supported dozens of teams building GUIs for embedded
systems. Many of them started with the same frustrations that I had—slow
development, hard-to-maintain code and limited design flexibility.
GUI Guider was a game-changer. It's more than just a tool—it's a complete
workflow that empowers developers to build better interfaces, faster. Whether
you're a solo engineer or part of a large team, it helps you focus on what
matters most: delivering a great user experience.
If you're working on an embedded project and haven't tried GUI Guider yet, I
highly recommend that you do.
