FS6500-FS4500 System Basis Chip – Embedded Software Driver

Overview

This embedded software solution provides high-level support for FS65/FS45 family SBCs. The driver implements basic functionality for FS65/FS45 interfacing as a SPI communication abstraction, watchdog settings and refresh, initialization procedure. The driver also provides a runtime register map.

Implementation of the FS65/FS45 software driver is generic, allowing to use any suitable 32 bit microcontroller with SPI module and enough number of GPIO pins. Example projects are a part of the package.

MoreLess

Features

FS65/FS45 interfacing as an SPI communication abstraction
Watchdog settings and refresh
Initialization procedure
Runtime register map
Examples for following platforms:
- S32 Design Studio for Power Architecture
  - MPC5777C-416DS and MPC5777C-516DS
  - DEVKIT-MPC5744P
- S32 Design Studio for Arm^®
  - S32K144EVB-Q100 with FRDM FS65/FS45 shield

MoreLess

Features

FS65/FS45 interfacing as an SPI communication abstraction
Watchdog settings and refresh
Initialization procedure
Runtime register map
Examples for following platforms:
- S32 Design Studio for Power Architecture
  - MPC5777C-416DS and MPC5777C-516DS
  - DEVKIT-MPC5744P
- S32 Design Studio for Arm^®
  - S32K144EVB-Q100 with FRDM FS65/FS45 shield

User Guide

Download

FS65/FS45 Software Driver

FS65/FS45 Software Driver

FS65/FS45 Software Driver

Previous Next

Supported Devices

FS4500: Grade 1 and Grade 0 safety power system basis chip with CAN flexible data transceiver
FS6500: Grade 1 and Grade 0 Safety Power System Basis Chip with CAN Flexible Data Transceiver

Target Applications

Automotive

Hybrid Electric Vehicle (HEV) Applications
