Name: MC33777A Evaluation Board with Isolated Daisy Chain
Price: 154.00 USD
Availability: InStock

Product Details

Supported Devices

Battery Management

Battery Sensors

MC33777: Battery Junction Box Monitor IC

Features

Key Features

Four current measurement channels (supporting two ASIL D current measurements)
16 analog inputs supporting redundant measurements
Two independent pyrotechnic switch controllers including driver stage

Connectivity

TPL communication, daisy chains support
Isolated power supply
All MC33777 inputs/outputs accessible with connectors
