CAN2TPL | Evaluation Board for BMA6X02 with CAN FD Gateway and TPL Communication

KIT6X02AF2T1 new

Roll over image to zoom in

The KIT6X02AF2T1 serves as a hardware evaluation tool in support of the BMA6X02. The BMA6X02 is a gateway router that can route TPL messages from the microcontroller (MCU) to two different TPL ports. It is designed for use in both automotive and industrial applications. The KIT6X02AF2T1 is an ideal board for rapid prototyping of the BMA6X02 for CAN or CAN FD interfaces, hence its nickname CAN2TPL.

Block Diagram

CAN2TPL board - KIT6X02AF2T1

KIT6X02AF2T1 Block Diagram
Get diagram PDF

Supported Devices

Battery Management

Battery Communication ICs

  • BMX6X02: General-Purpose BMS Communication Gateway and EIS Synchronization Controller

Interfaces

CAN with Flexible Data Rate

  • TJA144x: Automotive CAN FD Transceiver Family

Features

BMS Turn-Key Solution

  • SW-free battery evaluation solution
  • Easy integration with Battery Cell Controller (BCC) boards and Battery Junction Box (BJB) boards

Interfaces

  • Two electrical transport protocol link (ETPL) interfaces
  • CAN/CAN FD interface

Peripherals

  • Integrated SPI host enabling the control of external devices via SPI
  • Integrated GPIO enabling the integration of different sensors

Buy Options

KIT6X02AF2T1-Image

Click to expand

KIT6X02AF2T1
Active

CAN2TPL | Evaluation Board for BMA6X02 with CAN FD Gateway and TPL Communication.

    $177.00 USD
    In Stock :9

    Normally ships 1-2 business days

    ADD TO CART
