Industrial Communication Creator

INDUSTRIAL-COMMUNICATION-CREATOR

Roll over image to zoom in

Industrial Communication Creator (ICC) enables the configuration of industrial Ethernet stacks, device models and communication parameters in a unified environment. ICC simplifies the configuration of protocols such as PROFINET®, EtherNet/IP™, EtherCAT® and others, including device models, connection and object dictionaries. Using a unified configuration environment with protocol-specific plug-ins, developers can rapidly create industrial communication solutions based on NXP protocol stacks while working within a single tool.

Diagram

Industrial Communication Creator Product Development

Industrial Communication Creator Block Diagram
Get diagram PDF

Features

Industrial Ethernet Protocol Support

  • Plug-ins are available for the following NXP stacks and libraries:
    • PROFINET
    • EtherNet/IP
    • CANopen
    • EtherCAT
    • Modbus transmission control protocol/internet protocol (TCP/IP)
    • Control and communication-link (CC-Link) industrial Ethernet-time-sensitive networking (IE-TSN)*
    • CC-Link IE Field Basic*

      • *Coming soon

Tool Capabilities

  • Generates stack configuration files
  • Creates software model definitions (slots, modules, connections, object dictionaries, lines)
  • Generates device description files (GSDML, EDS, ESI, CSP+)
  • Provides guided configuration assistance
  • Detects common configuration errors
  • Step-by-step configuration workflow via task list

Cross-Platform Compatibility

  • Available for:
    • Windows
    • Linux

Supported Devices

  • i.MX94: i.MX 94 Applications Processor — Safe and Secure Industrial and Automotive Connectivity with Real-Time Control
  • i.MX-RT1180: i.MX RT1180 Crossover MCU with TSN Switch and EdgeLock®
