OpenSDA is a serial and debug adapter that is built into several NXP® evaluation boards. It provides a bridge between your computer (or other USB hosts) and the embedded target processor, which can be used for debugging, flash programming, and serial communication, all over a simple USB cable.
The OpenSDA hardware consists of a circuit featuring a Kinetis® K2x microcontroller with an integrated USB controller. On the software side, it implements a mass storage device bootloader which offers a quick and easy way to load OpenSDA applications such as flash programmers, run-control debug interfaces, serial to USB converters, and more.
DAPLink is the new and improved implementation of mbed bootloader and standard debugging interface. It includes a Kinetis K20-based circuit implementation that is portable to all OpenSDA v1 and v2/2.1, and new version on a different Kinetis based circuit. For comparison between DAPLink and all OpenSDA version, please refer to the table below on this page.
To update your board with OpenSDA applications
*Note: During development of OpenSDAv2 the reserved bootloader space was found to be too small. Thus a new version of OpenSDAv2 was subsequently released and named, OpenSDAv2.1.
| Version | Bootloader | Default Debugging Interface | Flash Programming | Virtual Serial Port | Source code available |
|---|---|---|---|---|---|
| OpenSDAv1 | P&E Micro | P&E Micro | .sda/.s19/.srec | Yes | No, proprietary |
| OpenSDAv2 | Arm/mbed | CMSIS-DAP | .bin | Yes | Yes, open source |
| OpenSDAv2.1 | Arm/mbed | CMSIS-DAP | .bin | Yes | Yes, open source |
| OpenSDAv2.2 | mbed DAPLink | DAPLink | .bin, .hex | Yes | Yes, open source |
