The TWR-KL28Z72M is a development board for the Kinetis KL28 32-bit MCUs.Features the Kinetis KL28 MCU with 512KB Flash, 128KB SRAM. Operates as a standalone debug tool and can also be combined and used as part of the modular Tower System development platform

Design Files

Software

Product Details

Supported Devices

Processors and Microcontrollers

KL Series Arm Cortex-M0+

KL28: Kinetis^® KL28-72/96 MHz, 512KB Flash, USB, Ultra-Low-Power Microcontrollers (MCUs) based on Arm^® Cortex^®-M0+ Core

Features

MKL28Z512VLL7 MCU (72 MHz, 512 KB flash, 128 KB RAM, 32 KB ROM, 100 LQFP packages)
Three-Axis Digital Accelerometer, MMA8451Q
Onboard serial and debug adapter
I/O headers for easy access to MCU I/O pins
Flexible power supply options: USB, coin cell battery, external source
Capacitive touchpad
Reset pushbutton
NMI and LLWU buttons
4 x LEDs

MCUXpresso Software and Tools

MCUXpresso Config Tools – A comprehensive suite of system configuration tools, including pins, clocks, SDK builder and more.

MCUXpresso SDK – An open-source software development kit (SDK) built specifically for your processor and evaluation board selections.

MCUXpresso IDE – An easy-to-use integrated development environment (IDE) for creating, building, debugging, and optimizing your application.

Buy Options

Click to expand

TWR-KL28Z72M
Active
Tower System Development Board for Kinetis KL28 MCUs.
- TWR-KL28Z72M Tower System module
- Quick start guide
- Supporting cable

$171.35 USD
For a quantity of 1

Order from distributors

Distributor	Region	Inventory	Inventory Date	Order
