Keil MCB1549 Evaluation Board

OM13064

Roll over image to zoom in

This board is no longer in production. The replacement for this board is the OM13056

The Keil MCB1549 Evaluation Board introduces you to the NXP® LPC1500 family and allows you to create and test working programs for this advanced architecture.

The MCB1549 Evaluation Board include MDK-Arm Evaluation Tools . These tools help you get started writing programs and testing the microcontroller and its capabilities. Many sample applications including several USB examples and quick start guide for the MCB1549 are included.

Product Details

Select a section:

Supported Devices

Processors and Microcontrollers

LPC1500 Arm Cortex-M3

  • LPC1517JBD48: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1517JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1518JBD100: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1518JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1519JBD100: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1519JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1547JBD48: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1547JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1548JBD100: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1548JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1549JBD100: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1549JBD48: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3
  • LPC1549JBD64: Motion Control 32-bit Microcontroller based on Arm® Cortex®-M3

Features

Processor

  • 72 MHz LPC1549 with Cortex-M3 processor in LQFP100 package

Memory

  • 36 kB On-Chip SRAM
  • 256 kB On-Chip Flash
  • MicroSD Card Interface

Connectivity

  • CAN interfaces
  • Serial/UART Port
  • DAP connector
  • Full speed USB 2.0

Power Management

  • Analog Voltage Control for ADC Input

Debug

    Debug Interface Connectors:

  • 20-pin JTAG (0.1 inches)
  • 10-pin Cortex debug (0.05 inches)
  • 20-pin Cortex debug + ETM Trace (0.05 inches)

Display

  • Color QVGA TFT LCD with touchscreen

Buy Options

  • OM13064

  • Keil MCB1549 Evaluation Board.

    • MCB1549 Development Board
  • $316.25 USD
  • For a quantity of 1
