OM7895
Active -
BGU8020 GNSS LNA evaluation board.
BGU8020 LNA evaluation board in ESD safe packing
BGU8020 GNSS LNA evaluation board
The BGU8020 GPS LNA evaluation board simplifies the evaluation of the BGU8020 LNA for the GPS application. The evaluation board enables testing of the device performance and requires no additional support circuitry. The board is fully assembled with the BGU8020, the input series inductor and a decoupling capacitor. The board is supplied with two SMA connectors for input and output connection to RF test equipment. The BGU8020 can operate from a 1.5 V to 3.1 V single supply and consumes about 2.0 mA.
Product Details
Features
- Noise figure (NF) = 0.85 dB
- Gain = 16.5 dB
- High input 1 dB compression point of -11 dBm
- High out of band IP3i of -2 dBm
Power Management
- Supply voltage 1.5 V to 3.1 V
- Covers full GNSS L1 band, from 1559 MHz to 1610 MHz
- Optimized performance at low supply current of 2.0 mA
- Power-down mode current consumption
- Requires only one input matching inductor and one supply decoupling capacitor
- Input and output DC decoupled
- ESD protection on all pins (HBM > 2 kV)
Size
- 1.1 mm x 0.7 mm x 0.37 mm; 0.4 mm pitch: SOT1232
- 180 GHz transit frequency - SiGe:C technology
- Integrated matching for the output
- Integrated temperature stabilized bias for easy design
