Kinetis V - Motor Control

(05:30min)

Kinetis V series is a family of devices targeting motor and power control applications for the mass market with a strong focus on enablement. See two elements of that story: a product benchmark showing relative product performance and the Kinetis motor suite -- a tool that speeds your development time to market.

See more demos at the nxp.community >

Category Products Features
Controllers (MCU and DSC)
Kinetis® V Series: Real-time Motor Control & Power Conversion MCUs based on Arm® Cortex®-M0+/M4/M7 Kinetis V Series MCUs are based upon the ARM® Cortex®-M0+, Cortex-M4 and Cortex-M7 cores and are designed for a wide range of BLDC.
MC56F84xxx: Digital Signal Controllers The MC56F84xxx is the market's fastest digital signal-processing MCU offering exceptional precision, sensing and control.
MC56F827xx: MC56F823xx and MC56F827xx Digital Signal Controllers The MC56F827xx/3xx DSP MCU family offers outstanding power consumption at runtime with exceptional performance, precision, and control.
KEA: Ultra-Reliable KEA Automotive Microcontrollers (MCUs) based on Arm® Cortex®-M0+ Core 32-bit ARM-based MCUs, up to 128K Flash and up to 16K RAM.
MPC560xP: Ultra-Reliable MPC560xP MCU for Automotive & Industrial Safety Applications 32-bit e200z0H MCU, 512K Flash, 40K RAM with ECC.
S12VR: S12VR Mixed-Signal MCU for Automotive & Industrial Relay Based Motor Control S12 based MCU with embedded 12V to 5V voltage regulator, LIN phy and dual relay driver.
S12ZVM: S12ZVM Mixed-Signal MCU for Automotive & Industrial Motor Control Applications S12Z based MCU with embedded 12V to 5V voltage regulator, LIN phy and 3-phase bridge gate driver.
S32K: 32-bit Automotive General Purpose Microcontrollers S32K is a series of 32-bit automotive MCUs based on ARM® Cortex-M® processors with Safety and Security HW support.
Voltage Regulator
MC33730: Power Supply with Multiple Linear Regulators Switch-mode power supply with multiple linear regulators.
TJA1042: High-speed CAN transceiver with Standby mode High Speed CAN I/F.
MC33903: SBC Gen2 with High-Speed CAN and LIN System Basis Chip with LIN and high-speed CAN I/Fs.
MC33904: System Basis Chip Gen2 with High Speed CAN System Basis Chip with high-speed CAN I/Fs.
MC33905: SBC Gen2 with High-Speed CAN and LIN System Basis Chip with LIN and high-speed CAN I/Fs.
MC34717: 5.0A 1.0MHz Integrated Dual Switch-Mode Power Supply 5.0A, 0.7V/3.6V adj., dual switch-mode power supply.
Power Stage Driver
GD3000: 3-Phase Brushless Motor Pre-Driver Three-Phase MOSFET Pre-Driver, 6V-58V, -20 to +105.
MC33937: 3 Phase Field Effect Transistor Pre-driver For >40 VDC, 3ph FET pre-driver.
Software and Tools
FREEMASTER: FreeMASTER Run-Time Debugging Tool Real-time control and debugging tool for Microcontrollers.
RTCESL: Real Time Control Embedded Software Motor Control and Power Conversion Libraries Embedded Software and Motor Control Libraries.
KINETIS MOTOR SUITE: Easy motor control development solution for BLDC and PMSM motors. Kinetis motor suite for tuning, observing and managing motor control system operation.
Model-Based Design Toolbox A comprehensive collection of tools that plug into the MATLAB®/Simulink® model-based design environment to support rapid application development with NXP® MCUs.

What's New

KINETIS-V-SERIES-DEMO-WN
Video

Motor Control Made Easy with Kinetis V Series MCUs

Kinetis® V Series MCUs support a wide range of BLDC, PMSM, and ACIM motor control as well as digital power conversion applications. Check out the drone demo powered by the Kinetis KV46 MCU family showcased at Embedded World 2018.

KINETIS-SERIES-V-DEMO-2-WN
Video

Sensorless BLDC Motor Control Made Easy with Kinetis V Series MCUs

Kinetis® V Series MCUs support a wide range of BLDC, PMSM, and ACIM motor control as well as digital power conversion applications. Check out this sensorless BLDC control demo powered by the Kinetis KV46 MCU family showcased at Embedded World 2018.
