S32K Automotive General-Purpose Microcontrollers
Scalable, low-power Arm® Cortex®-M series-based microcontrollers AEC-Q100 qualified with advanced safety and security and software support for industrial and automotive ASIL B/D applications in body, zone control and electrification. S32K MCUs are supported by a minimum of 15 years of product longevity and comprehensive, third-party software and tools ecosystem. Our S32K MCUs are part of the NXP S32 platform.
S32K Automotive General-Purpose MCUs
| Family | Products | Core | Memory | Features | Package | ISO 26262 | AEC-Q100 |
|---|---|---|---|---|---|---|---|
| S32K1 | S32K11x |
Arm Cortex-M0+ @ 48 MHz |
128 to 256 kB |
I2C, SPI, UART CSEc |
QFN-32 LQFP-48 LQFP-64 |
Up to ASIL B |
Up to Grade 1 (-40° C to +125° C) |
| S32K14x |
Arm Cortex-M4F @ up to 112 MHz Arm Cortex-M4F @ up to 80 MHz |
256 kB to 2 MB |
I2C, SPI, UART Ethernet (AVB) CSEc |
LQFP-48, 64, 100, 144, 176 MAPBGA-100 |
Up to ASIL B |
Up to Grade 0 (-40° C to +150° C) |
|
| S32K3 | S32K31x |
1x Cortex-M7 @ 120 MHz |
512 kB to 4 MB |
UART, I2C, SPI Ethernet (TSN) HSE_B |
LQFP-48 MAPBGA-257 HDQFP-172 HDQFP100 |
Up to ASIL B |
Grade 1 (-40 to 125° C) |
| S32K32x |
2x Cortex-M7 @ 160 MHz |
2 to 8 MB |
UART, I2C, SPI Ethernet (TSN) HSE_B |
HDQFP-172 MAPBGA-257 HDQFP100 |
Up to ASIL B |
Grade 1 (-40 to 125° C) |
|
| S32K33x |
3x Cortex-M7 @ 240 MHz |
8 MB |
UART, I2C, SPI Ethernet (TSN) HSE_B |
HDQFP-172 MAPBGA-289 |
Up to ASIL B |
Grade 1 (-40 to 125° C) |
|
| S32K34x |
1x LS Cortex-M7 @ 160 MHz |
1 to 8 MB |
UART, I2C, SPI Ethernet (TSN) HSE_B |
MAPBGA-289 MAPBGA-257 HDQFP-172 HDQFP100 |
Up to ASIL D |
Grade 1 (-40 to 125° C) |
|
| S32K35x |
1x LS Cortex-M7 + 1x Cortex-M7 @ 240 MHz |
8 MB |
UART, I2C, SPI Ethernet (TSN) HSE_B |
HDQFP-172 MAPBGA-289 |
Up to ASIL D |
Grade 1 (-40 to 125° C) |
|
| S32K39/37 Preproduction |
S32K39x, S32K37x |
1x LS Cortex-M7 + 2x split-lock Cortex-M7 @ 320MHz |
4M to 6M |
UART, I2C, SPI Ethernet (TSN) HSE_B |
MAPBGA-289 LQFP-EP-176 |
Up to ASIL D |
Grade 1 (-40 to 125° C) |
Learn More About the S32K Family
What are the main electric vehicle (EV) applications for each S32K3 family member?
- The S32K35 and S32K37 are ideal for battery management applications.
- The S32K39 is ideal for traction inverter applications, such as combined inverters or OBC and DC-DC applications.
- The S32K32 and S32K34 are optimized for 400 V BMS.
What are the target motor control applications for the S32K3 and the S32K9?
The S32K39 targets EV traction control inverters, offering optimized performance for the application, as well as the ability to combine on-board charger (OBC) and DCDC applications with advanced motor control peripherals.
The other S32K family members target motor control use cases in the chassis and body.
Is the S32K3 family appropriate for Brushless DC (BLDC), Permanent Magnet Synchronous Motor (PMSM) and AC Induction Motor (ACIM) motor drives?
With specialized peripherals such as eMIOS, Logic Control Unit (LCU), Body Cross-Triggering Unit (BCTU), and a large set of ADC converters, motor control applications are easily and safely deployed in S32K3 MCUs.
What applications can the S32K3 family perform in zonal vehicle architectures?
The S32K3 family is optimized for zone controllers performing IO aggregation and body functions. The MCUs are optimized for implementing actuation functions in the zone controller itself or in the connected edge nodes.
New S32K324 Triple Permanent Magnet Synchronous Motor Control Reference Design Board
Based on the 32-bit Arm® Cortex®-M7 S32K3 microcontroller and the GD3000 pre-driver.
Product Programs
Design Resources
S32K Evaluation and Development Tools
Development Tools
Reduce your time-to-market with our list of S32K development kits for prototyping.
S32K Reference Designs
Designs
From reference designs to complete form factors, our designs accelerate your time-to-market and reduce development risks.
Automotive Software Tools
Software
Discover our broad range of automotive software tools designed to help you to simplify and shorten your development time.
Discover the advantages of the award-winning S32K3 packaging. All the advantages of the classic QFP with better lead density.
S32K Community
Community
Join our open forum with thousands of on-going technical discussions moderated by NXP experts.
How To and Demo Videos
Videos
Get a technical deep dive and demonstration of key product features and benefits of the S32K microcontrollers.
New S32K344-WB: Evaluation Board for Automotive General Purpose
Based on the 32-bit Arm® Cortex®-M7 S32K344 offers dual cores configured in lockstep mode in a BGA 257 package.
