AC-DC Solutions

Whether your design draws from mains or battery, simple power conversion plays a critical role. Our power management portfolio includes integrated and cost-effective controllers to address a full range of AC-DC power conversion applications.

Converters	Description
AC-DC Controllers	Include efficient IC solutions for Switched Mode Power Supply (SMPS) controllers IC intended for flyback topologies, automatic discharge for low-power X capacitors, and Synchronous Rectifier (SR) controllers for switched mode power supplies with adaptive gate drive.
AC-DC Controllers with Integrated PFC	AC-DC controllers integrate a Power Factor Corrector (PFC) controller in a multichip IC.
AC-DC Controllers with Integrated Power Switch	These highly integrated devices reduce component count for more cost-effective application design while providing advanced control modes for exceptional efficiency.
Secondary Side Controllers	Our extremely efficient and highly integrated GreenChip ICs control synchronous rectification in a compact form factor.
Secondary Protocol Controllers	The USB Power Delivery (USB-PD) and Quick Charge^® 4+ fast charge controllers enables high-efficient adapters in an extremely compact form factor.

Range / Segment	Computing	Gaming	Display	Portable		Miscellaneous
				Type-C	non-Type-C
Applications	PCPower All in One Printer Cable Modems Gateways and Routers	Portable Games Consoles Wired Games Consoles	Flat Panel TVs Monitors	Smart Phones Tablet Notebook Ultralight PC Detachable laptop E-reader	Notebook Netbook Ultralight PC Convertible laptop	Consumer Home Appliance Industrial Health Care Personal Hygiene Lighting Auxiliary
15 - 45 W	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback	TEA1936xDB1475 27 W USB PD2.0 + QC2.0/3.0 PD: 5, 9, 12 V QC3.0: 3.3 V….12 V TEA1936xDB1530 27 W USB PD3.0, 5, 9, 12 V QC4.0/4.0+, 3.3 V….11 V TEA1936xDB1463 45 W USB PD2.0 + QC2.0/3.0 PD: 5, 9, 12, 20 V QC3.0: 3.3 V….12 V	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback
45 - 75 W	TEA1833DB1361 45 W/19.5 V FF/CCM Flyback	TEA1833DB1361 45 W / 19.5 V FF/CCM Flyback	TEA1833DB1361 45 W / 19.5 V FF/CCM Flyback	-	TEA1833DB1361 45 W / 19.5 V FF/CCM Flyback	TEA1833DB1361 45 W / 19.5 V FF/CCM Flyback
75 - 120 W	TEA1755DB1100 90 W/19.5 V QR/DCM PFC + QR/DCM Flyback TEA1716DB1255 90 W/19.5 V QR/DCM PFC + LLC	TEA1755DB1100 90 W/19.5 V QR/DCM PFC + QR/DCM Flyback	TEA1755DB1100 90 W/19.5 V QR/DCM PFC + QR/DCM Flyback TEA1716DB1255 90 W/19.5 V QR/DCM PFC + LLC		TEA1755DB1100 90 W/19.5 V QR/DCM PFC + QR/DCM Flyback TEA1716DB1255 90 W/19.5 V QR/DCM PFC + LLC	TEA1755DB1100 90 W/19.5 V QR/DCM PFC + QR/DCM Flyback TEA1716DB1255 90 W/19.5 V QR/DCM PFC + LLC
120 W	TEA1916DB1262 240 W/12 V QR/DCM PFC + LLC	TEA1916DB1262 240 W/12 V QR/DCM PFC + LLC	TEA1916DB1262 240 W/12 V QR/DCM PFC + LLC			TEA1916DB1262 240 W/12 V QR/DCM PFC + LLC
Companion IC	TEA1708DB1168 Active X-cap discharge TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1998DB1453 SR contr. IC / Vout = 2 - 8 V / 5 A low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET	TEA1708DB1168 Active X-cap discharge TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1998DB1453 SR contr. IC / Vout = 2 - 8 V / 5 A low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET	TEA1708DB1168 Active X-cap discharge TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1998DB1453 SR contr. IC / Vout = 2 - 8 V / 5 A low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET	TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1998DB1453 SR contr. IC / Vout = 2 - 8 V / 5 A low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET	TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET	TEA1708DB1168 Active X-cap discharge TEA1993DB1357 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1998DB1453 SR contr. IC / Vout = 2 - 8 V / 5 A low RDS_on MOSFET TEA1999DB1504 SR controller IC / Multi-Output voltages low RDS_on MOSFET TEA1999DB1546 SR controller IC / Multi-Output voltages low RDS_on MOSFET

NXP Smart Power Design Tools

Flyback SMPS Design Tool

The NXP Flyback SMPS Design Tool helps you design flyback power supplies using NXPs TEA172x, TEA173x, TEA183x, and TEA193x family.

Resonant SMPS Design Tool

The Resonant SMPS Design Tool is very helpful in simplifying your power supply design based on NXPs TEA1716 and TEA1916 LLC resonant controllers.

Smart Charging Design tool

The NXP USB-PD3.0 / QC4.0 Smart Charging Design tool helps you design a fast charging adapter supporting BC1.2, USB-PD3.0 and/or QC4.0 charging protocol.
