KW47: Evaluation Kit with Bluetooth® Low Energy 6.x

KW47-EVK updated
Active

Roll over image to zoom in

The KW47-EVK is an evaluation kit (EVK) for KW47 microcontroller units (MCUs) with 2.4 GHz Bluetooth® Low Energy (LE) 6.x support with channel-sounding capability, generic frequency shift keying (FSK) wireless connectivity and controller area network/local interconnect network (CAN/LIN) connectivity. The KW47’s highly sensitive 2.4 GHz radio incorporates a PCB meander antenna that can be bypassed for conducted testing through an onboard U.FL connector. The board includes an MCU-Link debug probe, CAN and LIN transceivers, buttons, switches, LEDs and integrated sensors, Arduino shield connectors, a MikroE Click connector and other headers.

Block Diagram

KW47-EVK

KW47-EVK Block Diagram
Get diagram PDF

Supported Devices

Wireless Connectivity

Bluetooth Low Energy

  • KW47: KW47: Automotive Bluetooth Core 6.x MCUs with Channel Sounding Localization for Access and Telematics

Features

Processor

  • Narrowband unit (NBU) 96 MHz radio controller based on Arm® Cortex®‑M33 CPU with a 2.4 GHz transceiver, supporting Gaussian frequency shift keying (GFSK) modulations for Bluetooth LE 6.0
  • Bluetooth LE controller stack
  • Transceiver drivers
  • Up to 2 MB flash
  • Up to 264 KB static random access memory (SRAM)
  • Peripherals optimized to meet the requirements of target applications

Connectivity

  • CAN connectivity support
  • LIN connectivity support
  • Arduino shield socket
  • mikroBUS™ socket

Debug

  • Joint Test Action Group (JTAG)

Power Management

  • Supports all DC-DC configurations

Wireless

  • 2.4 GHz PCB antenna

Supported Protocols

  • Use cases supported with Bluetooth LE and Controller Area Network Flexible Data-Rate (CAN FD) for IoT, industrial and automotive applications

Buy Options

KW47-EVK-Image

Click to expand

KW47-EVK
Active

KW47: Evaluation Kit with Bluetooth® Low Energy 6.x.

    $220.00 USD
    Pending Stock
    ADD TO CART
    Order from distributors
