Solution for Electrochemical Impedance Spectroscopy (EIS) in Battery Management Systems

BMS-EIS
Active

Click image to open expanded view

A battery management system (BMS) chipset, with electrochemical impedance spectroscopy (EIS)-enabled, integrates classical laboratory technology into in-vehicle use. This solution consists of three gateway devices, one to synchronize devices and transfer data, another as a cell module controller to measure voltage and voltage-based component response and the junction box controller to measure the current and current based excitation frequency component. NXP's new devices provide the benefits of EIS in chip packages that can be directly exchanged on the cell module and battery junction box (BJB) control units.

Block Diagram

BMS EIS

BMS EIS Block Diagram
Get diagram PDF

Supported Devices

Power Management

12 V, 24 V, and 48 V SBC Solutions

  • FS26: Safety System Basis Chip with Low Power, for ASIL D Systems

Processors and Microcontrollers

S32K Auto General-Purpose MCUs

  • S32K3: S32K3 Microcontrollers for Automotive General Purpose

Battery Management

Battery Communication ICs

  • BMX6X02: General-Purpose BMS Communication Gateway and EIS Synchronization Controller

Battery Sensors

  • BMA8420: Battery Junction Box Monitor IC with EIS Capability
  • TAA3033: TAA3033 Active Precharge Controller IC

Battery Cell Controllers

  • BMA7418: 18 Channel Li-Ion Battery Cell Controller IC ASIL D with EIS

Interfaces

CAN Partial Networking

  • TJA1145A: High Speed CAN Transceiver with Partial Networking, CAN FD Data Rates up to 5 Mbit/s

Features

Hardware Used Synchronization

  • The EIS chipset features a hardware-based synchronization algorithm, making the comparison of impedance data across the whole pack possible

Frequency Range

  • A wide frequency range 0.1 - 1 kHz for measurement of different effects is available, spanning from solid diffusion all the way to internal short-circuit assessment

Excitation Calibration Mechanism

  • A dual Fourier transform (DFT) current measurement integrated in the BJB device, enabling a precise calibration of the excitation

Buy Options

EVBMA6X02BMU-Image

Click to expand

EVBMA6X02BMU
Active

Optimized Battery Management Unit (BMU) for High Voltage Battery Management System (HVBMS) with BMA6X02, S32K358 and FS26.

  • Processing: Arm® Cortex®-M7
$222.00 USD
In Stock :4

Normally ships 1-2 business days

ADD TO CART
Order from distributors
EVBMA7X18DT1-Image

Click to expand

EVBMA7X18DT1
Active

BMA7X18 Evaluation Board with Isolated Daisy Chain.

    $129.00 USD
    In Stock :4

    Normally ships 1-2 business days

    ADD TO CART
    Order from distributors
    EVBMA8420T3-Image

    Click to expand

    EVBMA8420T3
    Active

    BMA8420 Electrochemical Impedance Spectroscopy (EIS) Battery Junction Box Evaluation Board.

      $249.00 USD
      In Stock :1

      Normally ships 1-2 business days

      ADD TO CART
      Order from distributors
