OM13089
Active -
LPCXpresso board for LPC54114.
LPCXpresso54114 board
The LPCXpresso family of boards provides a powerful and flexible development system for NXP®'s Cortex-M MCUs. The LPCXpresso54114 board has been developed by NXP to enable evaluation of and prototyping with the LPC54110 family of MCUs and its low power features make it as easy as possible to get started with your project.
LPCXpresso™ is a low-cost development platform available from NXP supporting NXPs Arm-based microcontrollers. The platform is comprised of a simplified Eclipse-based IDE and low-cost target boards which include an attached JTAG debugger. LPCXpresso is an end-to-end solution enabling embedded engineers to develop their applications from initial evaluation to final production.
The order code for this board is OM13089.
The LPCXpresso54114 board is now supported by Arm® Mbed™ OS and Zephyr OS, both open source embedded operating systems for developing the Internet of Things.
Product Details
Supported Devices
Processors and Microcontrollers
LPC54000 Arm Cortex-M4
- LPC541XX: Low-Power Microcontrollers (MCUs) Based on Arm® Cortex®-M4 Cores With Optional Cortex®-M0+ Co-processor
Features
Microcontroller
- M4 running at up to 100 MHz
- 256 kB flash
- 192 kB SRAM
LPC54114 Arm® Cortex®
Debug
- On-board, high-speed USB based, Link2 debug probe with ARM’s CMSIS-DAP and SEGGER J-Link protocol options
- Link2 probe can be used with onboard LPC54114 or external target
- Support for external debug probes
- Built-in power consumption measurement
- UART, I2C and SPI port bridging from LPC54114 target to USB via on-board debug probe
- FTDI UART connector
Power Management
- On-board 1.8/3.3 V or external power supply options.
Connectivity
- Full speed-speed USB device port
Memory
- 8 Mbit Macronix MX25R SPI flash.
User Interface
- Tri-color LED
- Target Reset, ISP, and WAKE buttons
Expansion
- LPCXpresso V3 expansion connectors with Arduino® UNO R3 support
- PMod™ / external host connector
