MagniV® and S12/S12x Automotive Development Platforms

16-bit S12 MagniV AEC-Q100 qualified mixed-signal MCU-based development platforms for motor control and sensor interface nodes applications.


General Purpose



Lighting



Motor Control


alt text

S12ZVM-EFP New

  • Type: Design

3-phase PMSM automotive electrical fuel pump (EFP)

alt text

S12ZVM-EWP New

  • Type: Design

3-phase PMSM Water Pump

alt text

MCSXSR1CS12ZVMNew

  • Type: Development Kit

For 3-phase Brushless Direct Current (BLDC) and Permanent Magnet Synchronous Motor (PMSM) control

alt text

S12ZVM32EVB

  • Type: Development Board

2-phase DC and 3-phase BLDC or PMSM

alt text

S12ZVMAEVB

  • Type: Development Board

2-phase DC and 3-phase BLDC or PMSM

alt text

S12ZVMBEVB

  • Type: Development Board

2-phase DC and 3-phase BLDC or PMSM

alt text

S12ZVMC256EVB

  • Type: Development Board

2-phase DC and 3-phase BLDC or PMSM

alt text

S12ZVMEVB

  • Type: Evaluation Board

2-phase DC and 3-phase BLDC or PMSM

alt text

S12ZVML-MINIXXX

  • Type: Evaluation Platform

3-phase sensorless BLDC and PMSM


Relay-based Motor Control


alt text

DEVKIT-S12VR64

  • Type: Development Board

For Relay-based Motor Control

alt text

S12VR32EVB

  • Type: Development Board

For Relay-based Motor Control

alt text

S12VR64EVB3

  • Type: Development Kit

3-phase sensorless BLDC


Vehicle Networking


alt text

DEVKIT-S12ZVC

  • Type: Development Board

For Controller Area Network (CAN) bus

alt text

DEVKIT-S12ZVL

  • Type: Development Board

For Local Interconnect Network (LIN)

alt text

DEVKIT-ZVL128

  • Type: Development Board

For Local Interconnect Network (LIN)

alt text

VLG-MC9S12ZVC

  • Type: Evaluation Board

For Controller Area Network (CAN) bus
