FRDM-MC-LVMTR: Low-Voltage, 3-Phase Motor for FRDM platform

Overview

Add 3-phase Brushless DC (BLDC) and Permanent Magnet Synchronous Motor (PMSM) motor control capabilities to your Freedom System designs with the NXP^® FRDM-MC-LVMTR kit.

Combine with an FRDM-KV31F or FRDM-KV10Z MCU board and either the FRDM-MC-LVBLDC for BLDC development or FRDM-MC-LVPMSM for PMSM development to create a complete low-cost reference platform.

Kit includes one low voltage, synchronous three-phase, sinusoidal Bemf BLDC motor with wiring for the three motor phases and hall effects signals.

Note: FRDM platform and shield sold separately.

MoreLess

Target Applications

Small and Medium Appliances

Specifications

Supported Devices

Processors and Microcontrollers

KV Series Cortex-M4/M0+/M7

KV1x : Kinetis^® KV1x-75 MHz, Entry-level 3ph FOC / Sensorless Motor Control MCUs based on Arm^® Cortex^®-M0+
KV3x : Kinetis^® KV3x-100–120 MHz, Advanced 3ph FOC / Sensorless Motor Control MCUs based on Arm^® Cortex^®-M4

MoreLess

Technical and Functional Specifications

	Linix 45ZWN24-40 motor wired for use with the FRDM-MC-LVPMSM and FRDM-MC-LVBLDC shields.
Power Management	Rated voltage: 24V Rated current: 2.3 amps Rated torque: 990 g.cm Rated Speed: 4000r/min

Buy

FRDM-MC-LVMTR ^Active
FRDM-MC-LVMTR, MOTOR 3-PH BLDC 4000r/min 24V 2.3A 990g.cm 40W, MFR. Linix, 45ZWN24-40
- Linix 45ZWN24-40 Motor.
Note: FRDM platform and shield are sold separately.

FRDM-MC-LVMTR
1 @ US
$35.00

Use Coupon

Availability?

Distributor

Distributor Name	Region	Inventory	Inventory Date

Upon selection of a preferred distributor, you will be directed to their web site to place and service your order. Please be aware that distributors are independent businesses and set their own prices, terms and conditions of sale. NXP makes no representations or warranties, express or implied, about distributors, or the prices, terms and conditions of sale agreed upon by you and any distributor.

Don't have an NXP coupon? You can purchase this product from one of our authorized distributors.
