DINK32: DINK32 Debug Monitor

Overview

DINK32 is a flexible software tool enabling initialization, evaluation, and debugging of selected legacy Power Architecture 32-bit microprocessors. Because this family of microprocessors spans a wide market range, DINK32 has to be extensible and portable, as well as being specific enough to be useful for a wide variety of applications. It is designed to be both a hardware and software debugging tool. DINK32 was written in ANSI C and built with modular routines around a central core. Only a few necessary functions were written in Power Architecture assembly.

For a complete list of products supported by DINK32, see the Supported Devices section below.

MoreLess

Features

Modification and display of general purpose, floating point, AltiVec^®™, and special purpose Registers
Assembly and disassembly of Power Architecture instructions for modification and display of code
Modification, display, and movement of system memory
A simplified breakpoint command that allows setting, display, and removal of breakpoints
Single-step trace and continued execution from a specified address
Automatic decompression of compressed s-record files while downloading

MoreLess

Features

Modification and display of general purpose, floating point, AltiVec^®™, and special purpose Registers
Assembly and disassembly of Power Architecture instructions for modification and display of code
Modification, display, and movement of system memory
A simplified breakpoint command that allows setting, display, and removal of breakpoints
Single-step trace and continued execution from a specified address
Automatic decompression of compressed s-record files while downloading

Dink Block Diagram

Dink Block Diagram

Dink Block Diagram

Previous Next

Supported Devices

MPC106: PCI Bridge/Memory Controller
MPC107: PCI Bridge/Memory Controller
MPC7410: Host Processor
MPC7447: Host Processor
MPC7447A: Host Processor
MPC7448: RISC Microprocessor
MPC745: Host Processor
MPC755: MPC755 and MPC745 Host Processors
P4080: QorIQ^® P4080/P4040/P4081 Multicore Communications Processors
