Freedom Development Platform for 48MHz KE1xZ64/32 MCUs

FRDM-KE16Z

Roll over image to zoom in

Product Details

Supported Devices

Processors and Microcontrollers

KE Series Arm Cortex-M4/M0+

Features

Microcontroller

  • MKE16Z64VLF4 MCU (Arm® Cortex® CM0+ 48LQFP package)

Connectivity

  • I/O headers for easy access to MCU I/O pins
  • CAN communication interface

Debug

  • Onboard debug circuit: K20DX128VFM5 (OpenSDA) with a virtual serial port

Sensors

  • NXP inertial sensor, FXOS8700CQ

User Components

  • Reset push button, two user buttons, and one RGB LED
  • Touch electrodes in the self-capacitive mode
  • Compatible with FRDM-TOUCH, FRDM-MC-LVBLDC, and Arduino® > boards

Buy Options

FRDM-KE16Z-Image

Click to expand

  • FRDM-KE16Z

  • Freedom Development Platform for 48MHz KE1xZ64/32 MCUs.

  • $44.85 USD
  • For a quantity of 1
    • Availability: In stock
    • Inventory: 16
    • Shipping: Normally ships 1-2 business days
Buy from NXPBuy From Distributor

Documentation

Quick reference to our documentation types.

5 documents

Design Resources

Select a section:

Design Files

1 design file

Software

1-5 of 8 software files

Show All

Note: For better experience, software downloads are recommended on desktop.
