32-Bit Microprocessor

Block Diagram

ColdFire MCF5441X Microprocessor Block Diagram

ColdFire MCF5441X Microprocessor Block Diagram

Features

  • Dual Ethernet with integrated L2 switch and high-precision hardware time stamping (IEEE®1588)
  • Low-power, real-time control industrial MPU addressing the rapid growth in industrial Ethernet
  • Integrated motion control/timer with high-speed precision pulse width modulator (PWM) and dual high-speed analog-to-digital converters (ADCs)
  • Integrated analog features including dual ADCs and DACs
  • Up to 10 universal asynchronous reveiver/transmitter (UARTS) possible, saving the expense of external UART expansion chips
  • Up to 64 KB SRAM
  • Up to 87 general-purpose input/outputs (GPIOs)
  • Rich set of serial connectivity to bring legacy applications into Ethernet based solutions
  • Turnkey support for embedded voice and VoIP applications
  • Complimentary MQX Software Solutions
  • This product is included in NXP®.s product longevity program, with assured supply for a minimum of 15 years after launch

Part numbers include: MCF54415CMJ250, MCF54416CMJ250, MCF54417CMJ250, MCF54418CMJ250.
